Precision Metal Film Fixed Resistors
Type R Series
Type R Series
Characteristics -
Electrical
YR8
Rated Power @ 70 °C (W)
Resistance Range (ohms) Min
Max
Tolerance (%)
Code Letter
Temperature Coefficient (ppm/°C)
Selection Series
Limiting Element Voltage - Nominal (V)
Maximum Overload Voltage (V)
Operating Temperature Range (°C)
Dielectric Strength (V)
Insulation Resistance Min Dry (Mohms)
Voltage Coefficient Max (ppm/V)
ER8
0.125
51R1
511K
CR8
ER1
CR1
0.25
10R
1M0
0.1
0.25
0.5
B
C
D
± 15
± 25
± 50
E96
250
500
-65 to +155
500
10,000
5
YR1
YR2
ER2
0.5
10R
1M0
CR2
± 15
± 25
200
400
± 50
± 15
± 25
350
700
± 50
The resistive element comprises a thin
film of nickel-chrome alloy evaporated
onto a high thermal conductivity
ceramic element. Metal end caps are
force fitted to the element prior to
spiralling to value. Tinned copper lead
wires are welded to the end caps and
the components are then coated. One
coat of phenolic resin is followed by
three coats of epoxy resin. All resistors
are tested for value and tolerance.
Dimensions
Key Features
I
Precision metal film resistors
with tolerance to 0.1% and
temperature coefficients to
15ppm.
Metal film resistors have
excellent stability under load
and severe environmental
conditions. They exhibit very
low noise current and voltage
coefficients. Precision metal
film resistors are particularly
suitable in all applications
where long-term stability is
important.
Style
R8
R1
R2
L*
3.3 ± 0.1
6.3 ± 0.3
9.5 ± 0.5
D
1.7 ± 0.2
2.3 ± 0.2
3.5 ± 0.5
d nom
0.45
0.6
0.6
I
* Length is measured in accordance with IEC 294
Derating Curve
100
80
Percent Rated Power
60
40
20
0
40
60 70 80
100
120
140
160
Ambient Temperature (°C)
Surface Temperature Vs Load
40
Temperature Rise (°C)
30
20
10
0
0
20
40
60
80
100
Percent Rated Power
Literature No. 1773265
Issued: 04-05
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
Precision Metal Film Fixed Resistors
Type R Series
Mounting
The resistors are suitable for processing on automatic insertion equipment and cutting and bending machines.
Marking
The resistors are marked with a five-band colour code in accordance with IEC 62.
Packaging
R series colour coded resistors are normally supplied taped in ‘ammo’ boxes of 1000 pieces.
All tape specifications are in accordance with IEC286-1.
Performance Characteristics
Evaluation of the performance characteristics is carried out with reference to IEC specifications
QC 400 000 and QC 400 100.
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.16
4.18
4.19
4.22
Long Term Tests ±(1% + 0.05 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70 °C
Endurance at 125 °C
Short Term Tests ±(0.25% + 0.05 ohm)
Overload
Robustness of terminations
Resistance to soldering heat
Rapid change of temperature
Vibration
How to Order
Orders for these components should include the following information:-
Type, tolerance code letter and value e.g.
YR1 B 24K3
Literature No. 1773265
Issued: 04-05
Dimensions are shown for
reference purposes only.
Dimensions are in millimetres
unless otherwise specified.
Specifications subject to
change.
www.tycoelectronics.com
passives.tycoelectronics.com
