Chip Inductors – 1008CT Series (2520)
The 0.055″ profile makes these parts ideal for low
clearance applications. Their simple construction en-
sures high reliability and stability, and they feature much
Inductance
2
(nH)
4.7 @ 50 MHz
8.2 @ 50 MHz
10 @ 50 MHz
15 @ 50 MHz
20 @ 50 MHz
30 @ 50 MHz
40 @ 50 MHz
50 @ 50 MHz
60 @ 50 MHz
70 @ 50 MHz
80 @ 50 MHz
90 @ 50 MHz
100 @ 50 MHz
Percent
3
tolerance
20,10,5
20,10,5,2
20,10,5
20,10,5,2
20,10,5,2
20,10,5,2
20,10,5,2
10,5,2
10,5,2,1
10,5,2,1
10,5,2,1
10,5,2
10,5,2
higher SRF values than ferrite alternatives. For free
evaluation samples, visit
www.coilcraft.com
or contact
Coilcraft.
SRF min
5
(MHz)
7500
5000
2700
3000
2400
2400
2000
1900
1800
1700
1400
1400
1000
DCR max
6
(Ohms)
0.15
0.22
0.25
0.22
0.33
0.38
0.43
0.48
0.52
0.55
0.56
0.61
0.63
Irms
7
(mA)
600
600
600
600
600
600
600
600
600
510
510
500
480
Part number
1
1008CT-040X_B_
1008CT-080X_B_
1008CT-100X_B_
1008CT-150X_B_
1008CT-200X_B_
1008CT-300X_B_
1008CT-400X_B_
1008CT-500X_B_
1008CT-600X_B_
1008CT-700X_B_
1008CT-800X_B_
1008CT-900X_B_
1008CT-101X_B_
28
40
40
40
50
50
60
60
60
60
60
65
60
Q min
4
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
@ 500 MHz
1. When ordering, please specify
tolerance
and
packaging
codes:
1008CT-101XJBC
Tolerance: F
= 1%
G
= 2%
J
= 5%
K
= 10%
M
= 20%
(Table shows stock tolerances in bold.)
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge),
use code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape (7500 parts per full reel).
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/
HP 4286A impedance analyzer with Coilcraft-provided correlation
pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured at using an Agilent/HP 4291A with an Agilent/
HP 16193 test fixture.
5. SRF measured using an Agilent/HP 8720D network analyzer and a
Coilcraft SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF840 test fixture.
7. Average current for a 15°C rise above 25°C ambient.
8. Operating temperature range
−40°C
to +125°C.
9. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
For part marking data see Color Coding section.
Specifications subject to change without notice.
Please check our website for latest information. Document 102-1
Revised 12/09/03
Document 102-2
1008CT Series (2520)
Typical Q vs Frequency
100
80
Typical L vs Frequency
100
80 nH
80
60 nH
80 nH
60 nH
Q Factor
60
Inductance (nH)
4.7 nH
30 nH
60
40
40
30 nH
20
20
0
1
10
100
1000
10000
0
1
10
100
1000
4.7 nH
10000
Frequency (MHz)
Frequency (MHz)
B
overall
F
A
G
F
E
terminal
C
I
J
I
D
Terminal wraparound:
approx 0.015/0,38 both ends
H
Land
Pattern
A max B max C max
0.115
2,92
0.110
2,79
0.050
1,27
D ref
0.020
0,51
E
0.080
2,03
F
G
H
I
J
0.020 0.060 0.100 0.040 0.050
0,51
1,52
2,54
1,02
1,27
Weight:
17.1 – 17.8 mg
Terminations:
Platinum/palladium/silver
Tape and reel:
2000/7″ reel; 7500/13″ reel 8 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Please check our website for latest information. Document 102-2
Revised 12/15/04
