5962-9063801HXA amplifier basic information:
5962-9063801HXA is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are,
5962-9063801HXA amplifier core information:
The minimum operating temperature of the 5962-9063801HXA is -55 °C and the maximum operating temperature is 125 °C. Its maximum average bias current is 0.00005 µA
When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-9063801HXA gain becomes 0.707 times the low-frequency gain is 1300 kHz.
The nominal supply voltage of 5962-9063801HXA is 35 V, and its corresponding nominal negative supply voltage is -35 V. The input offset voltage of the 5962-9063801HXA is 4300 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-9063801HXA:
5962-9063801HXA has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-9063801HXA amplifier additional information:
Its temperature grade is: MILITARY. The corresponding JESD-30 code is: O-MBFM-P8. The corresponding JESD-609 code is: e0. The material of the 5962-9063801HXA package is mostly METAL. And its package shape is ROUND.
5962-9063801HXA package pin format is: FLANGE MOUNT. Its terminal forms are: PIN/PEG.
5962-9063801HXA amplifier basic information:
5962-9063801HXA is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are,
5962-9063801HXA amplifier core information:
The minimum operating temperature of the 5962-9063801HXA is -55 °C and the maximum operating temperature is 125 °C. Its maximum average bias current is 0.00005 µA
When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the 5962-9063801HXA gain becomes 0.707 times the low-frequency gain is 1300 kHz.
The nominal supply voltage of 5962-9063801HXA is 35 V, and its corresponding nominal negative supply voltage is -35 V. The input offset voltage of the 5962-9063801HXA is 4300 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the op amp 0V (or close to 0V).)
Related dimensions of 5962-9063801HXA:
5962-9063801HXA has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8
5962-9063801HXA amplifier additional information:
Its temperature grade is: MILITARY. The corresponding JESD-30 code is: O-MBFM-P8. The corresponding JESD-609 code is: e0. The material of the 5962-9063801HXA package is mostly METAL. And its package shape is ROUND.
5962-9063801HXA package pin format is: FLANGE MOUNT. Its terminal forms are: PIN/PEG.
| Parameter Name | Attribute value |
| Parts packaging code | TO-3 |
| package instruction | , |
| Contacts | 8 |
| Reach Compliance Code | unknown |
| ECCN code | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Maximum average bias current (IIB) | 0.00005 µA |
| Nominal Common Mode Rejection Ratio | 80 dB |
| Maximum input offset voltage | 4300 µV |
| JESD-30 code | O-MBFM-P8 |
| JESD-609 code | e0 |
| Negative supply voltage upper limit | -50 V |
| Nominal Negative Supply Voltage (Vsup) | -35 V |
| Number of functions | 1 |
| Number of terminals | 8 |
| Maximum operating temperature | 125 °C |
| Minimum operating temperature | -55 °C |
| Package body material | METAL |
| Package shape | ROUND |
| Package form | FLANGE MOUNT |
| Certification status | Not Qualified |
| Filter level | MIL-PRF-38534 Class H |
| Supply voltage upper limit | 50 V |
| Nominal supply voltage (Vsup) | 35 V |
| surface mount | NO |
| Temperature level | MILITARY |
| Terminal surface | TIN LEAD |
| Terminal form | PIN/PEG |
| Terminal location | BOTTOM |
| Nominal Uniform Gain Bandwidth | 1300 kHz |
| Base Number Matches | 1 |
