1676952-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 1676952-2

1676952-2: Description1 ELEMENT, 100uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT; CategoryPassive components inductor; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

1676952-2 Overview

1 ELEMENT, 100uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

1676952-2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	compli
ECCN code	EAR99
DC Resistance	0.84 Ω
Nominal inductance(L)	100 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3638
Number of functions	1
Number of terminals	2
Maximum rated current	0.38 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

3638A101MT Product Details

Live Product Chat

Inductors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3638A101MT

(1676952-2)

T E I nternal N umber: 1 6 7 6 9 5 2 - 2

Product Highlights:

Inductor

Inductor Type = Shielded Power Wirewound

Lead Type = Surface Mount Terminals

Wirewound

Inductance = 100 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SHIELDED SMD POWER INDUC TOR SERIES 3638

(PDF, English)

Catalog Pages/Data Sheets:

Shielded SMD Power Inductor - Type 3638 Series - Tyc...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Shielded Power Wirewound

Element

= Wirewound

Shielded

= Yes

Electrical Characteristics:

Inductance (?H)

= 100

DC Resistance (?)

= 0.84

C urrent, Maximum (mA)

= 380

Package Type

= Taped and Reeled

Tolerance (%) = 20

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3638

Package, C omponent Size

= 6.0 x 6.0

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Operation/Application:

Application

= Power C ircuitry

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

1676952-2 Related Products

	1676952-2	3638A101MT
Description	1 ELEMENT, 100uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT	1 ELEMENT, 0.84uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Reach Compliance Code	compli	unknown
ECCN code	EAR99	EAR99
DC Resistance	0.84 Ω	0.84 Ω
Nominal inductance(L)	100 µH	0.84 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	3638	3638
Number of functions	1	1
Number of terminals	2	2
Maximum rated current	0.38 A	0.38 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	YES	YES
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	20%	20%
Base Number Matches	1	1
