4-1676963-9 datasheet, PDF - EEWORLD Datasheet

4-1676963-9: Description1 ELEMENT, 68uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT; File Size102KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

4-1676963-9 Overview

1 ELEMENT, 68uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

4-1676963-9 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1646066278
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	0
DC Resistance	0.165 Ω
Nominal inductance(L)	68 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
Minimum quality factor (at nominal inductance)	20
Maximum rated current	1.65 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	20%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Passive C omponents

Product Feature Selector

> Product Details

3625C680MT Product Details

Live Product Chat

Inductors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3625C680MT

(4-1676963-9)

T E I nternal N umber: 4 - 1 6 7 6 9 6 3 - 9

Product Highlights:

Inductor

Inductor Type = Unshielded Power Wirewound

Lead Type = Surface Mount Terminals

Wirewound

Inductance = 68 ?H

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SMD POWER INDUC TOR SERIES 3625

(PDF, English)

Catalog Pages/Data Sheets:

SMD Power Inductor - Type 3625 Series - Tyco Electro...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Inductor

Inductor Type = Unshielded Power Wirewound

Element

= Wirewound

Shielded

= No

Electrical Characteristics:

Inductance (?H)

= 68

DC Resistance (?)

= 0.165

C urrent, Maximum (mA)

= 1650

Quality Factor

= 20

Package Type

= Taped and Reeled

Tolerance (%) = 20

Body Related Features:

Lead Type

= Surface Mount Terminals

Series

= 3625

Package, C omponent Size

= 12.7 x 12.7

Mount Style

= Surface Mount

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Operation/Application:

Application

= High Power C ircuitry

Other:

Brand = Sigma Inductors

Additional Information:

Product Line Information

4-1676963-9 Related Products

	4-1676963-9	3625C680MT
Description	1 ELEMENT, 68uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT	1 ELEMENT, 0.165uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
Is it lead-free?	Lead free	Lead free
Is it Rohs certified?	conform to	conform to
Objectid	1646066278	1646065185
Reach Compliance Code	compliant	unknown
ECCN code	EAR99	EAR99
DC Resistance	0.165 Ω	0.165 Ω
Nominal inductance(L)	68 µH	0.165 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Number of functions	1	1
Number of terminals	2	2
Minimum quality factor (at nominal inductance)	20	20
Maximum rated current	1.65 A	1.65 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	NO	NO
surface mount	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND
Tolerance	20%	20%
