336SB-155.520 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> oscillator> 336SB-155.520

Preview

336SB-155.520: DescriptionPECL Output Clock Oscillator, 200MHz Max, 155.52MHz Nom; CategoryPassive components oscillator; File Size148KB，2 Pages; ManufacturerCTS

Download Datasheet Parametric View All

336SB-155.520 Overview

PECL Output Clock Oscillator, 200MHz Max, 155.52MHz Nom

336SB-155.520 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	ENABLE/DISABLE FUNCTION
Maximum control voltage	5 V
Minimum control voltage
maximum descent time	1.5 ns
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	100 ppm
frequency stability	20%
linearity	10%
Manufacturer's serial number	336
Installation features	SURFACE MOUNT
Maximum operating frequency	200 MHz
Nominal operating frequency	155.52 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	PECL
Output load	50 OHM
physical size	20.57mm x 13.84mm x 5.71mm
longest rise time	1.5 ns
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
maximum symmetry	55/45 %
Base Number Matches	1

Preview

Download Datasheet

View All

Preliminary Specification

Rev. X02

Model 336

“AnyDrive™ ” Series

Precision HFF VCXO

♦

Versatile Differential Output Stage

♦

PECL, LVDS, ECL, CMOS, CML, Sine

♦

Very Low Phase Jitter: < 0.5 pSec

♦

+3.3Vdc or +5.0Vdc Operation

♦

High Freq. Fundamental AT Crystal

♦

Proprietary Low Aging Inverted Mesa

♦

Output Enable Function

♦

Low Phase Noise

♦

Guaranteed Minimum Pull Range

Electrical Characteristics

Parameter

Power

Requirements

Power Supply

Supply Current

Frequency

Stabilities

Center

Frequency

Sym

Vcc

Icc

Conditions

±

5%

336L

±

5%

336S

Vcc=Max. (3.3Vdc)

50Ω . Load (5.0Vdc)

Min

3.135

4.75

Typical

3.30

5.0

Max

3.465

5.25

25

30

Unit

Vdc

mA

f

nom

10

155.52

77.760

38.88

19.44

200

MHz

Initial Tolerance

Freq. vs. Temp.

Freq. vs. Voltage

Freq. vs. Load

Freq. vs Time

(Aging)

Deviation

Characteristics

Control Voltage

Frequency

Deviation

Linearity

Absolute Pull

Range

f

cal

∆f/∆Temp

∆f/∆Vcc

∆f/∆RL

∆f/∆Time

Ta=+25°C

EFC=0.5Vcc

-10

±

20

+10

ppm

Vcc

±

5%

±

10% Variation

20 years

±

0.5

±

0.5

±

5

±

10

VC

∆f

Lin

APR

3.3V “ Version

L”

5.0V “ Version

S”

+25°C at time of

Shipment

Best Staight Line

Fit

Under all

conditions for the

life of the part (Ref.

to f

nom

)

-3db Point

0.0

±

85

-10

±

50

3.3

5.0

±

100

2

10

V

ppm

%

ppm

Input Impedance

Bandwidth

Waveform

Parameters

Symmetry

Amplitude

Rise/Fall Times

Load

Phase Jitter

Phase Noise

Zin

50

KΩ

KHz

Sym

Vo

tr, tf

RL

@ 50% Level

50Ω Load

20% to 80%

Output to Ground

12KHz to 20MHz

Bandwidth

1KHz

10KHz

45

0.200

50

55

0.250

1.5

<0.5

50

%

Vp-p

nSec

Ω

pSec RMS

dBc/Hz

-112

-145

♦ ♦ ♦

CTS Frequency Products

♦

400 W. North Street

♦

Carlisle, PA 17013

♦

717-243-5929

♦ ♦ ♦
