49536212 Product Details
MicroPower & Power Quadlok System
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Applies To Printed Circuit Board
Connector
Connector Assembly
Connector Style = Header
24 + 24 Positions, 48 Positions
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
49536212
TE Internal Number: 49536212
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
HEADER ASSY,24 + 24 POSITIONS RIGHT ANGLE ,MQS (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
24+24 WAYS MQS RIGHT ANGLE HEADERS WITH BOARD LOCKS (PDF, English)
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Connector Type = Connector Assembly
Sealed = No
Mounting Holes = Without
Mount Angle = Right Angle
Footprint (mm [in]) = 2.54 x 2.54 [.100 x .100]
Keyed = Yes
Termination Features:
Termination Method to PC Board = Through Hole Solder
Contact Features:
Contact Type = Tab
Contact Style = MQS
Number of MQS Contacts = 48
Contact Finish = Gold Flash
Contact Base Material = Phosphor Bronze
Housing Features:
Connector Style = Header
Centerline, Matrix (mm [in]) = 2.54 x 6.9 [.100 x .272]
Header Color = Yellow
Housing Material = PBT GF
Configuration Features:
Number of Positions = 24 + 24, 48
Staggered Centerline = Without
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C
RoHS/ELV Compliance History = Always was RoHS compliant
Identification Marking:
Key ID = CA
Conditions for Usage:
Applies To = Printed Circuit Board
Mates with Centerline = 2.54 x 6.90 [.100 x .272]
Other:
Brand = TE Connectivity
