"High Frequency Ceramic Solutions"
UWB Balun (3 - 8 GHz)
Detail Specification: 07/21/09
P/N 5500BL15U0100
Page 1 of 2
General Specifications
Part Number
Frequency (MHz)
Unbalanced Impedance
Differential Balanced Imp.
Insertion Loss
Return Loss
Phase Difference (degree)
Amplitude Difference
5500BL15U0100
3000 - 8000
50
Ω
100
Ω
1.8 dB max.
9.5 dB min.
180 ± 15
2.0 dB max.
Operating Temperature
Storage Temperature
Range
Reel Quantity
Power Capacity
-40 to +85°C
+5~+35°C, 12 mos. max.
Humidity 45~75%RH
4,000
0.5W max.
Terminal Configuration
No.
1
2
Function
Unbalanced Port (IN)
GND
GND
Balanced Port (OUT1)
GND
Balanced Port (OUT2)
3
T
g
b
4
5
6
2
1
Mechanical Dimensions
In
L
W
T
a
b
c
g
p
0.079 ± 0.004
0.049 ± 0.004
0.037 ± 0.004
0.012 ± 0.004
0.008 ± 0.004
0.012 +.004/-.006
0.014 ± 0.004
0.026 ± 0.002
mm
2.00 ± 0.10
1.25 ± 0.10
0.95 ± 0.10
0.30 ± 0.10
0.20 ± 0.10
0.30 +0.1/-0.15
0.35 ± 0.10
0.65 ± 0.05
L
c
a
p
3
W
4
5
6
Mounting Considerations
Mount these devices with brown mark facing up.
*
Line width should be designed to provide proper impedance matching characteristics.
Units: mm
0.35
Solder Resist
*
Land
Through-hole
(
φ
0.3)
0.8
1.0
*
0.30
*
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2009 Johanson Technology, Inc. All Rights Reserved
"High Frequency Ceramic Solutions"
UWB Balun (3 - 8 GHz)
Detail Specification: 07/21/09
P/N 5500BL15U0100
Page 2 of 2
Typical Electrical Performance (T=25°C)
)
)
)
)
)
)
)
Insertion and Return Loss
0
-10
-20
-30
2
3
4
)
dB(RL)
dB(IL)
5
)
6
7
8
9
freq, GHz
)
Amplitude and Phase Balance
)
2
Amp_difference
1
0
-1
-2
2
3
4
5
6
7
8
9
freq, GHz
)
200
Phase_difference
100
0
-100
-200
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2009 Johanson Technology, Inc. All Rights Reserved
