Embedded Power for
Business-Critical Continuity
ASA Series
6 Watts
Total Power:
6 Watts
Input Voltage: 12V, 24V or 48V
# of Outputs: Single, Dual
Rev. 06.15.06
ASA 6W Series
1 of 2
RoHS
Electrical Specifications
Input
Input range
Efficiency
2
9 to 36 VDC; 18 to 75 VDC
81%@5Vo
±2.0%
±0.5%
Single output: 1% @ 3.3Vo
Other: ± 0.5%
Dual output: ± 3.0%
3.3Vo, 5Vo: 100mV
12Vo: 120mV
15Vo: 150mV
Auto-restart
250KHz
±0.02 /°C
1500 VDC min.
10Mohm
1000pF
Output
Special Features
•
•
•
•
•
Encapsulated
Wide 4:1 input range
1.25" X 0.8” DIP package
1500Vdc I/O isolation
Single and Dual output
Voltage tolerance
Line regulation
Load regulation
Noise/ripple
Short circuit protection
Switching frequency
Temperature coefficient
Isolation
I/O isolation
Insulation resistance
Insulation capacitance
Environmental Specifications
Operating ambient temperature range
Storage temperature
Humidity
MTBF
RoHS Compliant
-40°C to +71°C (no derating)
-55°C to +105°C
5% to 95% (non-condensing)
1 Mhrs demonstrated MTBF
Safety
CE Mark
Embedded Power for
Business-Critical Continuity
Ordering Information
Input
Output 1
Maximum
Output 2 Voltage
Model Number
Voltage
Voltage
Power
3.96W
ASA01F18-L
9 -3 6V
3.3V @ 1.2A
5W
ASA01A18-L
9 -3 6V
5V @ 1.00A
6W
ASA00B18-L
9 -3 6V
12V @ 0.50A
6W
ASA00C18-L
9 -3 6V
15V @ 0.40A
-5V @ 0.5A
5W
ASA00AA18-L
9 -3 6V
5V @ 0.50A
-12V @ 0.25A
6W
ASA00BB18-L
9 -3 6V
12V@ 0.25A
-15V @ 0.20A
6W
ASA00CC18-L
9 -3 6V
15V @ 0.20A
3.96W
ASA01F36-L
18 - 75V
3.3V @ 1.2A
5W
ASA01A36-L
18 - 75V
5V @ 1.00A
6W
ASA00B36-L
18 - 75V
12V @ 0.50A
6W
ASA00C36-L
18 - 75V
15V @ 0.40A
-5V @ 0.5A
5W
ASA00AA36-L
18 - 75V
5V @ 0.50A
-12V @ 0.25A
6W
ASA00BB36-L
18 - 75V
12V@ 0.25A
-15V @ 0.20A
6W
ASA00CC36-L
18 - 75V
15V @ 0.20A
Please contact Astec for information on other output voltages, power ranges and configurations.
Available in RoHS 6 version only.
Astec Power
Rev. 06.15.06
ASA 6W Series
2 of 2
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 760 930 4600
Facsimile: +1 760 930 0698
Technical Support: +1 888 41 ASTEC
or +1 407 241 2752
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
Units 2111-2116, Level 21
Tower 1, Metroplaza
223, Hing Fong Road
Kwai Fong, New Territories
Hong Kong
Telephone: +852 2437 9662
Facsimile: +852 2402 4426
Mechanical Drawing
Top View
31.75
(1.25)
Pb
Dot
Vin -Vin
22.86
(0.90)
NC
NC
20.32
(0.80)
ASTEC
ASA01A36-L
For global contact, visit:
15.24
(0.60)
IN=48Vdc Nom. OUT=5Vdc
Date Code
RoHS
Bottom View
0.50
(0.02)
+Vin +Vin
-Vout
+Vout
www.astecpower.com
technicalsupport@astec.com
While every precaution has been taken to ensure
accuracy and completeness in this literature, Astec
Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
Printed in US A
Dot
Label
2.54
(0.10)
10.16
(0.40)
5.08
(0.20)
3.05
(0.12)
Top View
31.75
(1.25)
Emerson Network Power.
The global leader in enabling
business-critical continuity.
Dot
Pb
-Vin -Vin
22.86
(0.90)
COM
-Vout
AC Power
Connectivity
DC Power
Embedded Power
Inbound Power
Integrated Cabinet Solutions
Outside Plant
Precision Cooling
Site Monitoring and Services
EmersonNetworkPower. com
Emerson Network Power and the Emerson
Network Power logo are trademarks and
service marks of Emerson Electric Co.
©2006 Emerson Electric Co.
20.32
(0.80)
ASTEC
ASA00AA18-L
IN=9~36Vdc
RoHS
OUT=±5Vdc
Date Code
Bottom View
0.50
(0.02)
+Vin +Vin
COM
+Vout
15.24
(0.60)
Dot
Label
2.54
(0.10)
10.16
(0.40)
5.08
(0.20)
3.05
(0.12)
Notes:
1. All specifications subject to change without notice. Mechanical drawings are for reference only.
2. Warranty: 1 yr
3. Label and logo appearance may vary from what is shown on mechanical drawings.
