PD-94059D
30SCLJQ030
SCHOTTKY RECTIFIER
HIGH EFFICIENCY SERIES
Major Ratings and Characteristics
Characteristics
I
F(AV)
(Per Leg)
V
RRM
(Per Leg)
I
FSM
@ tp = 8.3ms half–sine (Per Leg)
V
F
@ 30Apk, T
J
= 125°C (Per Leg)
T
J
, T
stg
Operating and storage
30SCLJQ030 Units
30
30
130
0.82
-55 to 150
A
V
A
V
°C
30 Amp. 30V
Description/Features
The 30SCLJQ030 center tap Schottky rectifier has
been expressly designed to meet the rigorous
requirements of IR HiRel environments. It is packaged
in the hermetic surface mount SMD-0.5 ceramic
package. The device's forward voltage drop and
reverse leakage current are optimized for the lowest
power loss and the highest circuit efficiency for typical
high frequency switching power supplies and resonant
power converters. Full MIL-PRF-19500 quality
conformance testing is available on source control
drawings to TX, TXV and S quality levels.
Hermetically Sealed
Center Tap
Low Forward Voltage Drop
High Frequency Operation
Guard Ring for Enhanced Ruggedness and
Long term Reliability
Surface Mount
CASE STYLE
(ISOLATED BASE)
2
ANODE 1
1
COMMON
CATHODE
3
ANODE 2
Case Outline and Dimensions - SMD-0.5
1
International Rectifier HiRel Products, Inc.
2018-12-19
30SCLJQ030
Voltage Ratings
Part Number
V
R
Max. DC Reverse Voltage (V) (Per Leg)
V
RRM
Max. Working Peak Reverse Voltage (V) (Per Leg)
30SCLJQ030
30
Absolute Maximum Ratings
Parameter
I
F(AV)
Max. Average Forward Current (Per Leg)
See Fig. 5
I
FSM
Max. Peak One Cycle Non - Repetitive
Surge Current (Per Leg)
Electrical Specifications
Parameter
Limits
0.67
0.85
V
FM
Max. Forward Voltage Drop
(Per Leg) See Fig. 1
0.61
0.82
0.55
I
RM
C
T
L
S
Max. Junction Capacitance (Per Leg)
Typical Series Inductance (Per Leg)
Max. Reverse Leakage Current
(Per Leg) See Fig. 1
0.82
0.27
17
80
518
4.8
Units
V
V
V
V
V
V
mA
mA
mA
pF
nH
I
F
= 15A
I
F
= 30A
I
F
= 15A
I
F
= 30A
I
F
= 15A
I
F
= 30A
T
J
= 25°C
T
J
= 100°C
T
J
= 125°C
V
R
= 5V
DC
(1MHz, 25°C)
Measured from center of cathode pad to center
of anode pad
Conditions
T
J
= -55°C
T
J
= 25°C
T
J
= 125°C
V
R
= rated V
R
Limits
30
130
Units
A
A
Conditions
50% duty cycle @ T
C
= 80°C, square waveform
tp = 8.3 ms half-sine
Thermal-Mechanical Specifications
Parameter
T
J
Max. Junction Temperature Range
Limits
-55 to 150
-55 to 150
3.5
1.75
1.0
70 x 92
SMD-0.5
Units
°C
°C
°C/W
°C/W
g
mils
DC operation See Fig. 4
DC operation
Conditions
T
stg
Max. Storage Temperature Range
R
thJC
Max. Thermal Resistance, Junction
to Case (Per Leg)
R
thJC
Max. Thermal Resistance, Junction
to Case (Per Package)
Wt
Weight (Typical)
Die Size (Typical)
Case Style
Pulse Width < 300µs, Duty Cycle < 2%
2
International Rectifier HiRel Products, Inc.
2018-12-19
30SCLJQ030
100
125°C
Reverse Current - I R ( mA )
10
100°C
75°C
1
0.1
25°C
0.01
100
0.001
0
10
20
30
Reverse Voltage - V R (V)
Fig 2.
Typical Values of Reverse Current
Vs. Reverse Voltage (Per Leg)
Instantaneous Forward Current - I F (A)
10
1000
Tj = 125°C
Junction Capacitance - CT (pF)
T J = 25°C
Tj = 25°C
Tj = -55°C
1
0.0
0.2
0.4
0.6
0.8
1.0
Forward Voltage Drop - V F (V)
100
0
10
20
30
Reverse Voltage -V R (V)
Fig 1.
Max. Forward Voltage Drop Characteristics
(Per Leg)
Fig 3.
Typical Junction Capacitance Vs. Reverse Voltage
(Per Leg)
3
International Rectifier HiRel Products, Inc.
2018-12-19
30SCLJQ030
10
Thermal Response (Z
thJC
)
D = 0.50
1
0.20
0.10
0.05
0.1
0.02
0.01
P
DM
SINGLE PULSE
(THERMAL RESPONSE)
t
1
t
2
Notes:
1. Duty factor D = t
1
/ t
2
2. Peak T
J
= P
DM
x Z
thJC
+ T
C
0.0001
0.001
0.01
0.1
1
0.01
0.00001
t
1
, Rectangular Pulse Duration (sec)
Fig 4.
Max. Thermal Impedance ZthJC Characteristics (Per Leg)
180
Allowable Case Temprature - (°C)
160
140
120
100
80
60
40
20
0
0
10
20
30SCLJQ030
R thJC = 3.5°C/W
DC
30
40
50
Average Forward Current - I
F(AV) (A)
Fig 5.
Max. Allowable Case Temperature Vs.
Average Forward Current (Per Leg)
www.infineon.com/irhirel
Infineon Technologies Service Center: USA Tel: +1 (866) 951-9519 and International Tel: +49 89 234 65555
Leominster, Massachusetts 01453, USA Tel: +1 (978) 534-5776
San Jose, California 95134, USA Tel: +1 (408) 434-5000
4
2018-12-19
International Rectifier HiRel Products, Inc.
30SCLJQ030
