8
7
6
5
4
3
LTR
2
1
REVISION(S)
2
D
1. MATERIAL:
HEAT SINK: ALUM. (BLACK ANODIZE)
CLIP:
BLACK PEI (UL94-VO)
DESCRIPTION
ECN: 0S60-0055-04
ECR-06-014978
INIT
APP'D
7-FINS HS:
2.000 DIA.
0.892 HT.
O
A
E.T 03/11/04 S.D 03/11/04
E.T 6/28/06 V.K 6/30/06
D
3
1
3-LEG CLIP SIZE: 29mm
2. BEFORE THE HEATSINK APPLICATION, THE USER
SHOULD IDENTIFY THE SPECIFICATION OF MAXIMUM
LOAD ON THE BGA PACKAGE.
HEATSINK TORQUE SPECIFICATIONS CONVERTED TO FORCE.
BARE DIE PACKAGE:
1.5 POUND-FORCE INCH TORQUE = 7.5 POUND-FORCE
(0.17 NEWTON TORQUE = 33.36 NEWTON)
.016±.002
C
2.0 POUND-FORCE INCH TORQUE = 10.0 POUND-FORCE
(0.23 NEWTON METER TORQUE = 44.48 NEWTON)
FULL SIZE LID PACKAGE:
1.5 POUND-FORCE INCH TORQUE = 6.9 POUND-FORCE
(0.17 NEWTON TORQUE = 30.69 NEWTON)
C
DETAIL A
SCALE =6X
2.000±.020
B
B
2.0 POUND-FORCE INCH TORQUE = 9.3 POUND-FORCE
(0.23 NEWTON METER TORQUE = 41.37 NEWTON)
3. REMOVE CLIP WITH REMOVAL TOOL P/N: 1542616-1.
4. RoHS COMPLIANT AND CERTIFIED.
.095
.762 MAX
.245±.005
3/4 - 27 UNS - 2A
THREAD
SECTION B-B
B
.892
A
B
.115±.005
1.147 LIP LEG
1.220
ITEM
1
2
3
8
7
DESCRIPTION
MOUNTING CLIP
HEAT SINK
INTERFACE
QTY
1
1
1
DO NOT SCALE
A
° C/W @ ° C/W @ ° C/W @ ° C/W @
Ambient 200 LFM 400 LFM 600 LFM
20 Watts
----
----
1.56
1.36
Power
UNLESS OTHERWISE
SPECIFIED
TOLERANCES ARE:
.XX
.XXX
.XXXX
ANGLES
.
.
.
FILENAME
DRAWN BY:
DATE
CUSTOMER DRAWING
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
CONFIDENTIAL PROPERTY OF TYCO
ELECTRONICS. NOT TO BE DISCLOSED
TO OTHERS. REPRODUCED OR USED FOR
ANY PURPOSES EXCEPT AS AUTHORIZED
IN WRITING BY AN AUTHORIZED OFFICIAL
OF TYCO. MUST BE RETURNED TO TYCO
ON DEMAND, ON COMPLETION OF ORDERS
OR OTHER PURPOSES FOR WHICH LENT.
DIMENSONS ARE IN:
TITLE:
A
MATERIAL:
03/11/04
SEE NOTE
E.TAO
ENGINEER:
DATE
29mm HEATSINK
ASSEMBLY
PART NO:
S.D
PROJECT
03/11/04
SYSTEM
FINISH:
INCHES
SEE NOTE
TNIRD ANGLE
PROJECTION
SCALE:
1:1
SIZE:
5-1542007-9
SHEET:
1 OF 1
REV:
A
DWG. NO.
C-5-1542007-9
A
