2.54 mm pitch connector
Straight through hole type male connector for PCB
FFC-( )(T )AMEP( )( )
●
Configuration of product Part No.
For PCB
Straight Through hole
FFC- ( ) (T ) AMEP ( ) ( )
➀
➁
➂
➃
➄
➅
➄
Contact plating
1 : Gold plate
21: Tin copper plate
➅
Insulator color
Blank: Blue
B
: Black
➀
Series name
➁
No. of contacts: 1–52
➂
Length of contact
Blank: Standard (6 mm)
T, T1–T18 (Refer to the following
dimension table.)
➃
Type of contact
AMEP: 0.635 mm square contacts,
single row type
B
A
2.54
2.54
œ0.635
➁
C
➀
2.54
●
Dimensions
No. of
contacts
1
2
3
4
œ0.635
ø1
+0.1
0
5
6
7
8
9
10
2.54
– 0.05
+
A
–
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
B
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
No. of
contacts
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
A
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
B
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
D
11
A
– 0.1
+
●
Components
➀
Insulator
➁
Contact
Part No.
FFC- (1~52 ) AMEP( )( )
FFC- (1~52 )TAMEP( )( )
FFC- (1~52 )T1AMEP( )( )
FFC- (1~52 )T2AMEP( )( )
FFC- (1~52 )T3AMEP( )( )
FFC- (1~52 )T4AMEP( )( )
FFC- (1~52 )T5AMEP( )( )
FFC- (1~52 )T6AMEP( )( )
FFC- (1~52 )T7AMEP( )( )
FFC- (1~52 )T8AMEP( )( )
12
13
14
15
C
5
7
8.54
9.5
5.84
7.5
1.8
15.4
7.5
4
3.43
1.7
1.11
2
D
2.5
16
17
18
19
20
21
22
23
24
25
26
Recommended PCB layout
99.06 101.60
101.60 104.14
104.14 106.68
106.68 109.22
109.22 111.76
111.76 114.30
114.30 116.84
116.84 119.38
119.38 121.92
121.92 124.46
124.46 127.00
127.00 129.54
129.54 132.08
C
6
10.86
5.84
D
2.5
3.43
12.7
17.78
5.08
20.32
3
2.54
10.16
Part No.
FFC- (1~52 )T9AMEP( )( )
FFC- (1~52 )T10AMEP( )( )
FFC- (1~52 )T11AMEP( )( )
FFC- (1~52 )T12AMEP( )( )
FFC- (1~52 )T13AMEP( )( )
FFC- (1~52 )T14AMEP( )( )
FFC- (1~52 )T15AMEP( )( )
FFC- (1~52 )T16AMEP( )( )
FFC- (1~52 )T18AMEP( )( )
* T17 is obsolete.
5.72
6
5.72
Mating connectors:
DIC series or HKP series female connector
Z-220-( )FD (Cross section of contact: FFC-( )T9AMEP1(B) 0.635 mm square, Length of contact: 5 mm)
Through
hole
SMT
Press-in
IDC
Wire
Soldering Crimping wrapping
Others
