STANDARD POWER INDUCTORS - SURFACE MOUNT
SMP1812
SMP1812LF
*
Wirewound, Molded
PART
NUMBER
SMP1812-101K
SMP1812-121K
SMP1812-151K
SMP1812-181K
SMP1812-221K
SMP1812-271K
SMP1812-331K
SMP1812-391K
SMP1812-471K
SMP1812-561K
SMP1812-681K
SMP1812-821K
SMP1812-102K
SMP1812-122K
SMP1812-152K
SMP1812-182K
SMP1812-222K
SMP1812-272K
SMP1812-332K
SMP1812-392K
SMP1812-472K
SMP1812-562K
SMP1812-682K
SMP1812-822K
SMP1812-103K
SMP1812-123K
SMP1812-153K
SMP1812-183K
SMP1812-223K
SMP1812-273K
SMP1812-333K
TRADITIONAL
Pb
COMPLIANT
RoHS
L µH
@1 kHz
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
DCR
OHMS
MAX
FERRITE CORE
0.080
0.085
0.087
0.094
0.130
0.140
0.170
0.220
0.240
0.340
0.370
0.410
0.460
0.510
0.720
0.820
1.11
1.25
1.35
1.50
1.65
1.88
2.95
3.44
4.00
5.53
6.00
7.90
8.80
9.93
14.80
SATURATION
CURRENT
mA DC
2500
2200
2000
1830
1697
1513
1397
1250
1131
1060
990
871
772
752
693
614
515
465
425
376
366
336
297
267
238
214
191
175
158
143
129
CURRENT
RATING
mA DC
2018
1903
1619
1558
1325
1277
1158
1018
975
819
785
746
704
669
563
527
453
427
411
390
372
348
288
258
239
203
195
170
161
152
124
Suffix “K” for 10% tolerance
Custom designs are available to meet your specific requirements; please contact factory.
*Add “LF” suffix for RoHS requirement. Example: SMP1812-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
4.2/4.8
(0.165/0.189)
0.114/0.138 (2.9/3.5)
OVER TERMINAL
0.045/0.075 TYP
(1.14/1.91)
MARKING: GEC
PXXXK
EXAMPLE OF XXX
101 = 1.0uH
102 = 10uH
103 = 100uH
104 = 1000uH
0.40/0.80
(0.016/0.031)
TERMINAL
LENGTH, TYP
RECOMMENDED FOOT PRINT
0.059
(1.5)
0.110
(2.8)
0.177
(4.5)
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature
rise at an ambient temperature of 85°C
• Saturation Current is the approximate value
that will reduce the initial inductance by 5%
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
2200
8 mm
12 mm
13 in.
0.118/0.134
(3.0/3.4)
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
021914
