General Purpose Relays
Force Guided Relays
Force Guided Relay SR2M
n
n
n
SCHRACK
2 pole relay with force guided contacts according to EN 50205
Reinforced insulation between poles
Version for use in sockets
Typical applications
Emergency shut-off, press control, machine control, elevator and escalator
control, safety relays
F0188-D
ZT
Approvals
VDE 116064, UL E214025, TUV 968/EZ 111, CCC 2014010305743065
Technical data of approved types on request
Coil Data
(continued)
Coil versions, DC-coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
006
6
4.5
009
9
6.8
012
12
9
015
15
11.3
018
18
13.5
021
21
16
024
24
18
036
36
27
040
40
30
048
48
36
060
60
45
080
80
60
110
110
83
1)
1 form A + 1 form B contacts
(1 NO + 1 NC) or
2 form C contacts (2 CO)
According EN50205 only 1NO / 1NC (11-14 and 22-21 or 12-11 and
21-24) shall be used as force guided contacts.
Rated voltage
250VAC
Max. switching voltage
400VAC
Rated current
6A
Contact material
AgNi
Contact style
single contact, force guided
1 form A + B, 1 NO + 1NC
type A according to EN 50205
2 form C, 2CO
type B according to EN 50205
Min. recommended contact load
5V/10mA
Initial contact resistance
≤100mΩ at 1A, 24VDC
≤20Ω at 10mA, 5VDC
Frequency of operation, with/without load
6/300min
-1
Contact ratings, IEC60947-5-1,
on 1 form A (NO) contact
AC15 - 250V/3A
DC13 - 24V/3A
on the basis of DC13 - 24V/6A
under conditions specified in
product spec. 2158001
Mechanical endurance
10x10
6
operations
Contact Data
Contact arrangement
Release
voltage
VDC
0.6
0.9
1.2
1.5
1.8
2.1
2.4
3.6
4.0
4.8
6
8
11
Coil
resistance
Ω±10%
1)
51
116
206
321
483
630
823
1851
2286
3291
1)
5142
1)
9143
1)
17285
1)
Rated coil
power
mW
706
698
699
701
671
700
700
700
700
700
700
700
700
Coil resistance ±12%.
All figures are given for coil without pre-energization, at ambient temperature +23°C.
Insulation
Coil Data
Coil voltage range
Coil versions, DC-coil
Coil
Rated
Operate
code
voltage
voltage
VDC
VDC
005
5
3.8
07-2015, Rev. 0715
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
5 to 110VDC
Release
voltage
VDC
0.5
Coil
resistance
Ω±10%
1)
35.7
Rated coil
power
mW
700
Initial dielectric strength
between open contacts
between contact and coil
between adjacent contacts
Clearance/creepage
between open contacts
between contact and coil
between adjacent contacts
Insulation to EN 50178, type of insulation
between contact and coil
between adjacent contacts
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
1500V
rms
4000V
rms
3000V
rms
microdisconnection
≥8/8mm
≥5.5/5.5mm
reinforced
reinforced
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
1
General Purpose Relays
Force Guided Relays
Force Guided Relay SR2M
(Continued)
Other Data
SR2M
SR2M Plug-in
PCB layout / terminal assignment
Bottom view on solder pins
SCHRACK
Material compliance: EU RoHS/ELV, China RoHS, REACH, Halogen content
refer to the Product Compliance Support Center at
www.te.com/customersupport/rohssupportcenter
Ambient temperature
-25 to 70°C
Category of environmental Protection
IEC 61 810
RTIII
RTII
Weight
20g
Resistance to soldering heat THT
IEC 60068-2-20
260°C/5s
-
Packaging/unit
tube/20 pcs.
For more detailed information see product specification 2158001
2 form C, 2 CO contacts
S0163-CO
Accessories
For details see datasheet
Accessories Force Guided Relay SR2M plugin
NOTE: indicated contact ratings and electrical endurance data for direct
wiring of relays (according IEC 61810-1); for relays mounted on sockets
deratings may apply.
S0163-BJ
Dimensions
1 form A + 1 form B contacts, 1 NO + 1 NC
SR2M
S0163_CU
S0273-BB
SR2M Plug-In
S0163-CV
2
07-2015, Rev. 0715
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
3,6
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
General Purpose Relays
Force Guided Relays
Force Guided Relay SR2M
(Continued)
Product code structure
V23047
Relay with force guided contacts SR2M
Version
A1
standard
P1
Plug-In
Coil
Coil code: please refer to coil versions table (e.g. 024=24VDC)
Contact set
A
single contact
Contact material
5
AgNi
Contact configuration
01
2 form C contacts (2 CO)
11
1 form A + 1 form B contacts ( 1 NO + 1 NC)
Other types on request
SCHRACK
Typical product code
V23047
-A1
012
-A
5
11
Type
Product code
V23047-A1005-A501
V23047-A1005-A511
V23047-A1006-A501
V23047-A1006-A511
V23047-A1009-A501
V23047-A1009-A511
V23047-A1012-A501
V23047-A1012-A511
V23047-A1018-A501
V23047-A1018-A511
V23047-A1021-A501
V23047-A1021-A511
V23047-A1024-A501
V23047-A1024-A511
V23047-A1036-A501
V23047-A1036-A511
V23047-A1040-A501
V23047-A1040-A511
V23047-A1048-A501
V23047-A1048-A511
V23047-A1060-A511
V23047-A1110-A501
V23047-A1110-A511
V23047-P1005-A501
V23047-P1009-A501
V23047-P1012-A501
V23047-P1021-A501
V23047-P1024-A501
V23047-P1036-A501
V23047-P1110-A501
Version
Standard
wash tight
Cont. material
AgNi
Contact arrangement
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
1 A + 1 B, (1 NO + 1 NC)
2 form C (CO)
Coil
5VDC
6VDC
9VDC
12VDC
18VDC
21VDC
24VDC
36VDC
40VDC
48VDC
60VDC
110VDC
5VDC
9VDC
12VDC
21VDC
24VDC
36VDC
110VDC
Part number
1393258-2
7-1415006-1
3-1415011-1
6-1415011-1
1393258-3
7-1415011-1
1393258-4
1393258-5
1393258-8
1393258-9
1-1393258-1
1-1393258-2
1-1393258-5
1-1393258-7
2-1393258-0
8-1415011-1
2-1393258-1
2-1393258-2
3-1415006-1
9-1415011-1
2-1393258-3
1-1415012-1
2-1415012-1
7-1415543-4
7-1415543-5
7-1415543-6
7-1415543-7
7-1415543-8
7-1415543-9
8-1415543-0
Plug-in
for socket use
07-2015, Rev. 0715
www.te.com
© 2015 Tyco Electronics Corporation,
a TE Connectivity Ltd. company
Datasheets and product specification
according to IEC 61810-1 and to be used
only together with the ‘Definitions’ section.
Datasheets and product data is subject to the
terms of the disclaimer and all chapters of
the ‘Definitions’ section, available at
http://relays.te.com/definitions
Datasheets, product data, ‘Definitions’ sec-
tion, application notes and all specifications
are subject to change.
3
