S102T02 Series
S202T02 Series
S102T02 Series
S202T02 Series
∗
I
T
(rms)≤2A, Zero Cross type
Low profile SIP 4pin
Triac output SSR
Non-zero cross type is also available. (S102T01
Series/
S202T01 Series)
■
Description
S102T02 Series
and
S202T02 Series
Solid State
Relays (SSR) are an integration of an infrared emitting
diode (IRED), a Phototriac Detector and a main output
Triac. These devices are ideally suited for controlling
high voltage AC loads with solid state reliability while
providing 3.0kV isolation (V
iso
(rms)) from input to out-
put.
■
Agency approvals/Compliance
1. Recognized by UL508, file No. E94758 (as models No.
S102T02/S202T02)
2. Approved by CSA 22.2 No.14, file No. LR63705 (as
models No.
S102T02/S202T02)
3. Package resin : UL flammability grade (94V-0)
■
Applications
1. Isolated interface between high voltage AC devices
and lower voltage DC control circuitry.
2. Switching motors, fans, heaters, solenoids, and
valves.
3. Power control in applications such as lighting and
temperature control equipment.
■
Features
1. Output current, I
T
(rms)≤2.0A
2. Zero crossing functionary (V
OX
: MAX. 35V)
3. Slim 4 pin low profile SIP package
4. High repetitive peak off-state voltage
(V
DRM
: 600V,
S202T02 Series)
(V
DRM
: 400V,
S102T02 Series)
5. High isolation voltage between input and output
(V
iso
(rms) : 3.0kV)
6. Lead-free terminal components are also available
(see Model Line-up section in this datasheet)
7. Screw hole for heat sink
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
1
Sheet No.:D4-A01601EN
Date Apr. 28. 2004
© SHARP Corporation
S102T02 Series
S202T02 Series
■
Absolute Maximum Ratings
Parameter
Symbol
Forward current
I
F
Input
Reverse voltage
V
R
RMS ON-state current
I
T
(rms)
Peak one cycle surge current
I
surge
Repetitive
S102T02
V
DRM
peak OFF-state voltage
S202T02
Output
Non-Repetitive
S102T02
V
DSM
peak OFF-state voltage
S202T02
Critical rate of rise of ON-state current dI
T
/dt
Operating frequency
f
*1
Isolation voltage
V
iso
(rms)
Operating temperature
T
opr
Storage temperature
T
stg
*2
Soldering temperature
T
sol
*1 40 to 60%RH, AC for 1minute, f=60Hz
*2 For 10s
*3 Refer to Fig.1, Fig.2
*4 f=60Hz sine wave, T
j
=25˚C
start
(T
a
=25˚C)
Rating
Unit
*3
50
mA
6
V
*3
2
A
*4
20
A
400
V
600
400
V
600
40
A/µs
45
to 65
Hz
3.0
kV
−25
to
+100
˚C
−30
to
+125
˚C
260
˚C
Soldering area
■
Electro-optical Characteristics
Parameter
Symbol
Conditions
MIN.
−
V
F
I
F
=20mA
Forward voltage
Input
−
I
R
V
R
=3V
Reverse current
I
DRM
−
V
D
=V
DRM
Repetitive peak OFF-state current
V
T
(rms) I
T
(rms)=2A, Resistance load, I
F
=20mA
−
ON-state voltage
I
H
−
−
Output
Holding current
dV/dt
V
D
=2/3•V
DRM
30
Critical rate of rise of OFF-state voltage
Critical rate of rise of OFF-state voltage at commutaion (dV/dt)c T
j
=125˚C,
V
D
=2/3•V
DRM
, dI
T
/dt=−1.0A/ms
4
I
FT
V
D
=6V,
R
L
=30Ω
Minimum trigger current
−
V
OX
I
F
=8mA
Zero cross voltage
−
R
ISO
DC500V, 40 to 60%RH
Isolation resistance
10
10
V
D
(rms)=100V, AC50Hz, I
F
=20mA
−
S102T02
I
T
(rms)=2A, Resistance load
Transfer Turn-on time
t
on
V
D
(rms)=200V, AC50Hz, I
F
=20mA
charac-
−
S202T02
teristics
I
T
(rms)=2A, Resistance load
V
D
(rms)=100V, AC50Hz, I
F
=20mA
−
S102T02
I
T
(rms)=2A, Resistance load
t
off
Turn-off time
V
D
(rms)=200V, AC50Hz, I
F
=20mA
−
S202T02
I
T
(rms)=2A, Resistance load
TYP.
1.2
−
−
−
−
−
−
−
−
−
−
−
−
−
1.5mm
(T
a
=25˚C)
MAX.
1.4
100
100
1.7
25
−
−
8
35
−
10
ms
10
10
ms
10
Unit
V
µA
µA
V
mA
V/µs
V/µs
mA
V
Ω
Sheet No.: D4-A01601EN
4
