STANDARD RF INDUCTORS - SURFACE MOUNT
SMRF1010
SMRF1010LF
*
PART
NUMBER
SMRF1010-010K
SMRF1010-012K
SMRF1010-015K
SMRF1010-018K
SMRF1010-022K
SMRF1010-027K
SMRF1010-033K
SMRF1010-039K
SMRF1010-047K
SMRF1010-056K
SMRF1010-068K
SMRF1010-082K
SMRF1010-100K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Epoxy Coated, Chip Inductor
L
µH
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.100
Q
MIN
60
57
55
52
50
49
48
45
42
39
36
34
32
TEST
FREQ
MHz
PHENOLIC CORE
50
50
50
50
50
50
50
50
50
50
50
50
50
SRF
MHz
MIN
2700
2450
2200
2000
1800
1625
1450
1335
1220
1110
1000
915
830
DCR
OHMS
MAX
0.060
0.069
0.078
0.093
0.108
0.114
0.120
0.133
0.145
0.170
0.195
0.212
0.230
CURRENT
RATING
mA DC
1270
1190
1110
1030
950
925
900
860
820
760
705
675
650
continued next page
All part numbers provide 10% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: SMRF1010-010KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
Wrap around
Gold Plated Termination
on Ceramic Base
0.075
(1.91)
MAX
0.090/0.110
(.2.28/2.79)
SQ
Wrap around
Gold Plated Termination
on Ceramic Base
0.075
(1.91)
MAX
0.090/0.110
(.2.28/2.79)
SQ
NOTES:
0.015 (0.381) MIN Terminal Width
• Operating Temperature Range:
-55°C to +125°C
RECOMMENDED FOOT PRINT
• Current Rating is based on a 35°C
temperature rise at an ambient
temperature of 90°C
0.10
• DWV 500 Vrms @ Sea Level
(2.54)
80 Vrms @ 70,000 Feet
• Epoxy-encapsulated for environmental
protection and superior strength to
0.13
withstand all types of reflow soldering
(3.30)
• Terminations are Gold Plated Nickel
TAPE AND REEL SPECS:
0.015 (0.381) MIN Terminal Width
0.05
(1.27)
in. (mm)
0.10
(2.54)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
2000
4 mm
12 mm
7 in.
www.gowanda.com
0.13
(3.30)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
022714
STANDARD RF INDUCTORS - SURFACE MOUNT
continued from previous page
SMRF1010
SMRF1010LF
*
PART
NUMBER
SMRF1010-120K
SMRF1010-150K
SMRF1010-180K
SMRF1010-220K
SMRF1010-270K
SMRF1010-330K
SMRF1010-390K
SMRF1010-470K
SMRF1010-560K
SMRF1010-680K
SMRF1010-820K
SMRF1010-101K
SMRF1010-121K
SMRF1010-151K
SMRF1010-181K
SMRF1010-221K
SMRF1010-271K
SMRF1010-331K
SMRF1010-391K
SMRF1010-471K
SMRF1010-561K
SMRF1010-681K
SMRF1010-821K
SMRF1010-102K
SMRF1010-122K
SMRF1010-152K
SMRF1010-182K
SMRF1010-222K
SMRF1010-272K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Epoxy Coated, Chip Inductor
L
µH
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
Q
MIN
30
25
25
25
25
25
22
22
22
22
22
22
22
22
22
22
24
24
24
24
22
22
22
24
25
25
25
25
Wrap around
25
TEST
FREQ
MHz
FERRITE CORE
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
750
650
550
450
375
300
235
215
195
175
160
145
130
115
105
85
77
70
68
60
55
50
48
40
35
30
28
25
22
0.125
0.175
0.200
0.220
0.230
0.235
0.240
0.260
0.278
0.520
0.530
0.540
0.740
0.840
0.920
1.000
1.150
1.400
1.550
1.800
2.000
2.200
2.500
3.450
3.800
5.600
5.800
6.400
6.900
880
745
695
665
650
645
635
610
590
435
430
425
360
340
325
310
290
260
250
230
220
210
195
165
160
135
130
125
120
SRF
MHz
MIN
DCR
OHMS
MAX
CURRENT
RATING
mA DC
All part numbers provide 10% tolerance on inductance
on Ceramic Base
Custom designs are available to meet your specific requirements; please contact factory
Gold Plated Termination
*Add “LF” suffix for RoHS requirement. Example: SMRF1010-010KLF
(1.91)
0.090/0.110
(.2.28/2.79)
SQ
Wrap around
Gold Plated Termination
on Ceramic Base
0.075
MAX
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
0.075
(1.91)
MAX
0.090/0.110
(.2.28/2.79)
SQ
0.13
(3.30)
NOTES:
0.015 (0.381) MIN Terminal Width
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C
temperature rise at an ambient
temperature of 90°C
0.10
• DWV 500 Vrms @ Sea Level
(2.54)
80 Vrms @ 70,000 Feet
• Epoxy-encapsulated for environmental
protection and superior strength to
withstand all types of reflow soldering
• Terminations are Gold Plated Nickel
TAPE AND REEL SPECS:
0.015 (0.381) MIN Terminal Width
0.05
(1.27)
in. (mm)
0.10
(2.54)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
2000
4 mm
12 mm
7 in.
www.gowanda.com
0.13
(3.30)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
022714
