The Value Leader
BNC to BNC Coax Cable Assemblies:
Used in Serial Digital,
Communication, HDTV, and Broadband Applications
• UL Listed Cable: Ensures quality and consistency in the cable construction.
• Boot is molded to cable connector for added strength: Limits the
amount of bending the cable is exposed to at the connector to prevent
cable breakage.
• Gold center pins: Ensures that there is a high quality connection
maintaining the best return loss in high definition applications.
• Machined Brass Connectors: Unlike die-cast connectors,
machined brass connectors have more precise tolerances,
strength and positive mating meaning low signal loss for precise
video and data applications.
• 95% Shielding: Keeps unwanted RF interference from infiltrating your signal giving
you nice, clean output.
• 80º temperature rating: Applicable to any application found indoors.
• Lengths Available up to 100 ft.: Easily route cables into other rooms or floors.
• Individually bagged
™
F Cables with Screw-on Ends:
Used in Broadband Applications
• UL Listed Cable: Ensures quality and consistency in the cable
construction.
• RG-6: Cable type that is standard in the video and cable TV industry
• Molded Ends: Limits the amount of bending the cable is exposed to
at the connector to prevent cable breakage.
• Screw-on F-Type Connectors: Ensure positive connection thus
eliminating shadows in the picture.
• Lengths Available up to 100 ft.: Easily route cables into other
rooms or floors.
• Available in black or white: Easily hide the cable along walls or behind equipment.
• Individually bagged
Molded BNC to BNC Cable Assemblies
RG58/U, BNC Male to Male
Instrumentation & Data
RG59/U, BNC Male to
MaleVideo & General
BNC to BNC Coax Cable Technical
Specifications
Conductor
Insulation
RG58
Material
BC
No./mm
1/0.813
Material
LDPE
Color
Natural
Diameter (mm)
2.95
Material
BC
No./mm
16/7/0.12
Material
PVC
Thickness (mm)
0.72
Color
Black
Outer Diameter (mm)
4.95 ±0.15
Tensile Strength
1,500 psi
Nominal Impedance (Ohm)
53.5
Nominal Capacitance (pF/m)
93.5
Attenuation 100MHz (db/km)
138
Voltage Rating
5.0kv
UL Standard
1354
RG59
CCS
1/0.643
LDPE
Natural
3.71
BC
16/7/0.12
PVC
0.9
Black
6.0 ±0.15
1,500 psi
73
68.9
125
7.0kv
1354
RG62
CCS
1/0.643
LDPE
Natural
3.71
BC
16/7/0.12
PVC
1
Black
6.15 ±0.15
1,500 psi
93
44.3
102
3.0kv
1354
50 Ohm
Part No.
58-012-1M
58-024-1M
58-036-1M
58-048-1M
58-060-1M
58-072-1M
58-120-1M
58-180-1M
58-300-1M
58-600-1M
58-900-1M
58-1200-1M
Length
12 inch
24 inch
36 inch
48 inch
60 inch
72 inch
10 feet
15 feet
25 feet
50 feet
75 feet
100 feet
75 Ohm
Part No.
59-012-1M
59-024-1M
59-036-1M
59-048-1M
59-060-1M
59-072-1M
59-120-1M
59-180-1M
59-300-1M
59-600-1M
59-900-1M
59-1200-1M
Length
12 inch
24 inch
36 inch
48 inch
60 inch
72 inch
10 feet
15 feet
25 feet
50 feet
75 feet
100 feet
Braided Shielding
Jacket
General
BC = Bare Copper CCS = Copper Clad Steel LDPE = Low Density PE
RG62/U, BNC Male to
MaleComputer & Lab
93 Ohm
Part No.
62-024-1M
62-036-1M
62-048-1M
62-060-1M
Length
24 inch
36 inch
48 inch
60 inch
Assembled BNC to
BNC Cable Assemblies
RG58/U, BNC Male to Male
Instrumentation & Data
F Series Cable Technical Specifications
RG-6
Conductor
Insulation
Material
No./mm
Material
Color
Diameter (mm)
Braided Shielding
Jacket
Material
No./mm
Material
Thickness (mm)
Color
Outer Diameter (mm)
General
Tensile Strength
Nominal Impedance (Ohm)
Nominal Capacitance (pF/m)
Attenuation 100MHz (db/km)
Voltage Rating
UL Standard
CCS
1/1.02
FPE
White
4.7
OFC
16/4/0.12
PVC
1
Black or White
7.2 ±0.2
1,500 psi
73
59
89
3.0kv
1354
50 Ohm
Part No.
58-024-1A
58-036-1A
58-048-1A
58-060-1A
Length
24 inch
36 inch
48 inch
60 inch
F Series Cables
RG-6
Video & General
Part No.
Black
F6-3B
F6-6B
F6-10B
F6-12B
F6-15B
F6-25B
F6-50B
F6-75B
F6-100B
White
F6-3W
F6-6W
F6-10W
F6-12W
F6-15W
F6-25W
F6-50W
F6-75W
F6-100W
L BNC-0805
Length
3’
6’
10’
12’
15’
25’
50’
75’
100’
3’
6’
10’
12’
15’
25’
50’
75’
100’
Copyright © 2005 Test Products International, Inc.
CCS = Copper Clad Steel
FPE = Foam Polyethylene
OFC = Oxygen Free Copper
Test Products International, Inc.
9615 SW Allen Blvd., Ste. 104 • Beaverton, OR 97005
503-520-9197 • Fax: 503-520-1225
www.testproductsintl.com
