FB_S-2W Series
2W, FIXED INPUT, 5200V ISOLATED & UNREGULATED
SINGLE OUTPUT DC-DC CONVERTER
multi-country patent protection
RoHS
FEATURES
5.2KVDC Isolation
SIP Package,small footprint
Temperature Range: -40°C to +85°C
Continuous Short circuit protection
No Heatsink Required
No External Component Required
Internal SMD Construction
Industry Standard Pinout
RoHS Compliance
PRODUCT PROGRAM
Input
Part
Number
FB0505S-2W
FB0509S-2W
FB0512S-2W
FB0515S-2W
FB1205S-2W
FB1209S-2W
FB1212S-2W
12
10.8-13.2
5
4.5-5.5
Voltage (VDC)
Nominal
Range
Voltage
(VDC)
5
9
12
15
5
9
12
15
5
24
21.6-26.4
9
12
15
Output
Current (mA)
Max
400
222
167
133
400
222
167
133
400
222
167
133
Min
40
23
17
14
40
23
17
14
40
23
17
14
74
77
77
77
75
78
80
78
75
77
80
79
Efficiency
(%, Typ)
APPLICATIONS
The FB_S-2W Series are specially designed
for applications where a group of polar power
supplies are isolated from the input power
supply in a distributed power supply system on
a circuit board.
These products apply to:
1) Where the voltage of the input power supply
is fixed (voltage variation
≤ ±10%);
2) Where isolation is necessary between input
and output (isolation voltage
≤5200VDC);
3) Where the regulation of the output voltage
and
the
output
ripple
noise
are
not
demanding.
Such as: purely digital circuits, ordinary low
frequency analog circuits, and IGBT power
device driving circuits.
FB1215S-2W
FB2405S-2W
FB2409S-2W
FB2412S-2W
FB2415S-2W
ISOLATION SPECIFICATIONS
Item
Isolation voltage
Isolation resistance
Isolation capacitance
Test Conditions
Tested for 1 minute and 1mA max
Test at 1000VDC
Min
5200
1000
10
Typ
Max
Units
VDC
MΩ
pF
COMMON SPECIFICATIONS
Item
Storage humidity range
Test Conditions
Min
Typ
Max
95
-40
-55
1.5mm from case for 10 seconds
15
85
125
300
30
°C
Units
%
MODEL SELECTION
Operating temperature
Storage temperature
Rat ed Power
P acka ge Style
Outpu t Vo ltag e
I nput Vo ltage
P rod uc t Ser ies
FB0505S-2W
Lead temperature
Temp. rise at full load
Cooling
Short circuit protection
Case material
Free air convection
Continuous
Plastic(UL94-V0)
3500
4.3
K hours
g
MORNSUN Science & Technology co.,Ltd.
Address:
2th floor 6th building, Hangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
http://www.mornsun-power.com
MTBF
Weight
Note:
1. All specifications measured at TA=25°C, humidity<75%, nominal input voltage and rated output load
unless otherwise specified.
2.See below recommended circuits for more details
MORNSUN reserves the copyright
Specifications subject to change without notice.
FB_S-2W
A/1-2008
Page 1 of 2
OUTPUT SPECIFICATIONS
Item
Output power
Line regulation
For Vin change of
±1%
10% to 100% load(5V output)
Load regulation
10% to 100% load (9V output)
10% to 100% load (12V output)
10% to 100% load (15V output)
Output voltage accuracy
Temperature drift
Ripple & Noise*
Switching frequency
100% full load
20MHz Bandwidth
Full load,
nominal input
(5V input)
(12V/24V input)
150
45
50
10
8.3
6.8
6.3
Test conditions
Min
0.2
Typ
Max
2
±1.2
15
15
15
15
%
Units
W
%
Recommended testing and application circuit
If you want to further decrease the input/output
ripple,
an
“LC”
filtering
network
may
be
connected to the input and output ends of the
DC/DC converter, see (Figure 1).
Single Output
L
L
Vin
Cin
+Vo
DC DC
Cout
GND
0V
See tolerance envelope graph
0.03
250
%/°C
mVp-p
KHz
(Figure 1)
It should also be noted that the inductance and
the frequency of the
“LC”
filtering network should
be staggered with the DC/DC frequency to avoid
mutual interference. However, the capacitance of
the output filter capacitor must be proper. If the
capacitance is too big, a startup problem might
arise. For every channel of output, provided the
safe and reliable operation is ensured, the
greatest capacitance of its filter capacitor sees
(Table 1).
EXTERNAL CAPACITOR TABLE (Table 1)
*Test ripple and noise by
“parallel
cable” method. See detailed operation instructions at Testing of
Power Converter section, application notes.
TYPICAL CHARACTERISTICS
Vin
(VDC)
5
12
24
-
Ambient Temperature
( C )
Cin
(uF)
10
4.7
2.2
-
Single Vout
(VDC)
5
9
12
15
Cout
(uF)
10
4.7
2.2
1
It’s not recommend to connect any external
capacitor in the application field with less than 0.5
watt output.
OUTLINE DIMENSIONS & PIN CONNECTIONS
First Angle Projection
RECOMMENDED FOOTPRINT
Top
view,grid:2.54mm(0.1inch)
diameter:1.00mm(0.039inch)
Single Output
Output Voltage Regulation and Over-voltage
Protection Circuit
The simplest device for output voltage
regulation,
over-voltage
and
over-current
protection is a linear voltage regulator with
overheat protection that is connected to the input
or output end in series (Figure 2).
S ingle O u tpu t
Vn
i
R EG
REG
+Vout
1
2
5
7
GND
DC DC
0V
1 2
5
FOOTPRINT DETAILS
Pin
(Figure 2)
Overload Protection
Under normal operating conditions, the output
circuit of these products has no protection
against overload. The simplest method is to
connect a self-recovery fuse in series at the input
end or add a circuit breaker to the circuit.
No parallel connection or plug and play.
Function
Vin
GND
0V
+Vo
Note:
Unit:mm(inch)
Pin secti on:0.50*0.30mm(0.020*0.012inch)
Pin diameter tolerances: 0.10mm( 0.004inch)
General tolerances: 0.25mm( 0.010i nch)
1
2
5
7
APPLICATION NOTE
Requirement on output load
To ensure this module can operate efficiently and reliably, During operation, the minimum
output load is
not less than 10%
of the full load, and that
this product should never be
operated under no load!
If the actual output power is very small, please connect a resistor
with proper resistance at the output end in parallel to increase the load; or use our company’s
products with a lower rated output power (FB_S-1W).
MORNSUN reserves the copyright
Specifications subject to change without notice.
FB_S-2W
A/1-2008
Page 2 of 2
