Z50FG: Description2,500 V - 10,000 V rectifiers 0.50 A - 1.5 A forward current 200 ns recovery time; CategoryDiscrete semiconductor diode; File Size95KB，2 Pages; ManufacturerVOLTAGE MULTIPLIERS INC.; Websitehttp://www.voltagemultipliers.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

Z50FG Overview

2,500 V - 10,000 V rectifiers 0.50 A - 1.5 A forward current 200 ns recovery time

Z50FG Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	VOLTAGE MULTIPLIERS INC.
package instruction	E-XALF-W2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	9.5 V
JESD-30 code	E-XALF-W2
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	1 A
Package body material	UNSPECIFIED
Package shape	ELLIPTICAL
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	5000 V
Maximum reverse recovery time	0.2 µs
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

2,500 V - 10,000 V Rectifiers

0.50 A - 1.5 A Forward Current

200 ns Recovery Time

AXIAL LEADED

HERMETICALLY SEALED

Z25FG

Z50FG

Z100FG

4

ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS

Part

Number

Working

Reverse

Voltage

(Vrwm)

Average

Rectified

Current

(Io)

Reverse

Current

@ Vrwm

(Ir)

Forward

Voltage

1 Cycle Repetitive Reverse

Surge

Recovery

Current

Time

tp=8.3ms

(3)

(Ifsm)

(Ifrm)

(Trr)

25°C

Amps

25°C

Amps

25°C

ns

Thermal

Impedance

Junction

Cap.

@50VDC

@ 1kHZ

(Cj)

25°C

pF

(Vf)

25°C

Volts

Amps

u

J-L

L=000 L=.125 L=.250

°C/W

55°C(1) 100°C(2) 25°C 100°C

Volts

Z25FG

Z50FG

Z100FG

Amps

µA

2500

5000

10000

1.50

1.00

0.50

1.00

0.50

0.25

1.0

25

6.5

9.5

13.0

2.00

1.00

0.60

60

40

25

10

8

5

200

3

6

12

20

16

8

(1)TL=55°C L=0.375" (2)TL=100°C L=0.375" (3)If=0.5A, Ir=1.0A, Irr=0.25A • Op.Temp.= -65°C to +175°C Stg.Temp.= -65°C to +200°C

.215(5.5)

MAX.

A

Part

Z25FG

Z50FG

A

.350(8.89) MAX.

.400(10.16) MAX.

1.00(25.4)

MIN.

.040 ±.003

(1.02 ±.08)

Z100FG

Dimensions: In. (mm) • All temperatures are ambient unless otherwise noted. • Data subject to change without notice.

VOLTAGE MULTIPLIERS INC.

8711 W. Roosevelt Ave.

Visalia, CA 93291

TEL

559-651-1402

FAX

559-651-0740

www.voltagemultipliers.com

105
