GPDP3320
RECTIFIER DIODE
VOLTAGE UP TO
AVERAGE CURRENT
SURGE CURRENT
BLOCKING CHARACTERISTICS
Characteristic
V
RRM
V
RSM
I
RRM
Repetitive peak reverse voltage
Non-repetitive peak reverse voltage
Repetitive peak reverse current, max.
V
RRM
, single phase, half wave, Tjmax
2200 V
3200 A
31 kA
Conditions
Value
2200 V
2200 V
75 mA
FORWARD CHARACTERISTICS
I
F(AV)
I
F(AV)
I
FSM
I²t
V
F(TO)
Average forward current
Average forward current
Surge forward current
I² t for fusing coordination
Threshold voltage
Forward slope resistance
Peak forward voltage, max
T
j
= T
jmax
T
j
= T
jmax
Forward current I
F
= 4000 A, Tj = 25°C
Sine wave,180° conduction, Th = 55°C
Sine wave,180° conduction, Tc = 85°C
Non rep. half sine wave, 50 Hz, V
R
= 0 V, T
j
= T
jmax
3200 A
2975 A
31 kA
4805 kA²s
0,79 V
0,09 m
Ω
1,20 V
r
F
V
FM
SWITCHING CHARACTERISTICS
Q
rr
I
rr
t
rr
V
FP
Rverse recovery charge, typ
Reverse recovery current
Reverse recovery time
Forward recovery voltage
T
j
= T
jmax
, di/dt =
A/µs
T
j
= T
jmax
, I
F
= 2000 A, di/dt = -5 A/µs
V
R
= 100 V
1900 µC
A
µs
V
THERMAL AND MECHANICAL CHARACTERISTICS
R
th(j-c)
R
th(c-h)
T
jmax
T
stg
F
Thermal resistance (junction to case)
Thermal resistance (case to heatsink)
Max operating junction temperature
Storage temperature
Clamping force ± 10%
Mass
Double side cooled
Double side cooled
0,02
°C/W
0,005 °C/W
175 °C
-40 / 175 °C
22 kN
500 g
Document GPDP3320T001
RECTIFIER DIODE
GPDP3320
Current rating - sine wave
Power loss - sine wave
190
Case temperature [°C]
170
150
P
F
[W]
130
110
90
70
50
0
30°
60°
90°
120°
5000
4000
30
90
60°
120
180°
3000
2000
1000
180°
0
4000
0
1000
2000
I
F
[A]
3000
4000
1000
2000
I
F
[A]
3000
Maximum surge current
d.s. cooled
35
7000
30
25
I
FSM
[A]
I
F
[A]
20
15
10
5
0
1
10
100
Forward voltage drop
6000
5000
4000
3000
2000
1000
0
0,5
0,7
0,9
V
F
[V]
1,1
1,3
1,5
Number of cycle current pulses [n]
Tj=Tjmax
Thermal Impedance (j-c)
Distributed by
0,025
0,020
0,015
0,010
0,005
0,000
0,001
Z
TH(j-c)
[°C / W]
0,01
0,1
1
10
100
Time [s]
I
n the interest of product improvement Green Power Solutions reserves the right to change any specification given in this data sheet
without notice.
Document GPDP3320T001
