HER201 THRU HER208
HIGH EFFICIENCY RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Forward Current -
2.0 Amperes
Features
Low power loss, high efficiency
Low leakage
Low forward voltage drop
High current capability
High speed switching
High current surge
High reliability
Mechanical Data
Case:
Molded plastic
Epoxy:
UL94V-0 rate flame retardant
Lead:
MIL-STD-202E method 208C guaranteed
Mounting Position:
Any
Weight:
0.014 ounce, 0.39 gram
DIM ENSIONS
DIM
A
B
C
D
inches
Min.
0.228
0.102
0.028
1.000
Max.
0.299
0.142
0.034
-
Min.
5.8
2.6
0.71
25.40
mm
Max.
7.6
3.6
0.86
-
Note
Maximum Ratings and Electrical Characteristics
Ratings at 25
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Symbols
HER
201
HER
202
HER
203
HER
204
HER
205
HER
206
HER
207
HER
208
Units
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375" (9.5mm) lead length at T
A
=50
Peak forward surge current,
8.3mS single half sine-wave superimposed
on rated load (MIL-STD-750D 4066 method)
Maximum instantaneous forward voltage at 2.0A DC
Maximum full load reverse current average, full cycle
0.375" (9.5mm) lead length at T
L
=55
Maximum DC reverse current
at rated DC blocking voltage
T
A
=25
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R(AV)
I
R
T
rr
C
J
T
J
, T
STG
50
35
50
100
70
100
200
140
200
300
210
300
2.0
60.0
400
280
400
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
1.0
1.3
100.0
5.0
50
30
-65 to +150
1.5
1.7
Volts
A
A
Maximum reverse recovery time (Note 1)
Typical junction capacitance (Note 2)
Operating and storage temperature range
Notes:
(1) Test conditions: I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
(2) Measured at 1.0MHz and applied reverse voltage of 4.0 volts
75
20
nS
F
1
