SHINDENGEN
Super Fast Recovery Rectifiers
Single
SF10L60U
6
00V 10A
OUTLINE DIMENSIONS
Case : FTO-220
Unit : mm
RATINGS
●Absolute Maximum Ratings (If not specified Tc=25℃)
Item
Symbol
Conditions
Storage Temperature
Tstg
Operating Junction Temperature
Tj
Peak Reverse Voltage
V
RM
Average Rectified Forward Current
I
O
50Hz sine wave, resistance load, Tc=85℃
Peak Surge Forward Current
I
FSM
50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=25℃
Dielectric Strength
Vdis
Terminals to case, AC 1 minute
Mounting Torque
TOR
(Recommended torque)
●Electrical Characteristics (If not specified Tc=25℃)
Item
Symbol
Conditions
Forward Voltage
I
F
=10A, Pulse measurement
V
F
Reverse Current
V
R
=V
RM
, Pulse measurement
I
R
Junction Capacitance
Cj
f=1MHz, VR=10V
Reverse Recovery Time
trr
I
F
=0.5A, I
R
=1A
Thermal Resistance
θjc
junction to case
Ratings
-55∼150
150
600
10
120
2
0.5(0.3)
Ratings
Max.3.0
Max.25
Typ.55
Max.25
Max.2.0
Unit
℃
℃
V
A
A
kV
N・
m
Unit
V
μA
pF
ns
℃/W
Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
SF10L60U
50
Forward Power Dissipation
DC
Forward Power Dissipation P
F
[W]
40
0.5
SIN
30
0.1
0.05
20
0.2
0.3
D=0.8
10
0
0
2
4
6
8
10
12
14
16
Average Rectified Forward Current I
O
[A]
Tj = 150°C
I
O
0
t
p
D=t
p
/T
T
SF10L60U
200
Peak Surge Forward Capability
I
FSM
10ms 10ms
1 cycle
Peak Surge Forward Current I
FSM
[A]
150
non-repetitive,
sine wave,
Tj=25°C before
surge current is applied
100
50
0
1
2
5
10
20
50
100
Number of Cycles [cycles]
