SES Series
ESD Protector
SES12VN1010-5
ROHS
Description
These integrated transient voltage suppressor devices
(TVS) are designed for applications requiring transient
overvoltage protection. They are intended to be used in
sensitive equipment such as wireless headsets, PDAs,
digital cameras, computers, printers, communication
systems, medical equipment, and other applications.
Their integrated design provides very effective and
reliable protection for four separate lines using only one
package. These devices are ideal for situations where
board space is at a premium.
Feature
Solid-state silicon-avalanche technology
DFN-5 package
Uni-Directional or Bi-Directional protection
Protects up to four data lines
65 Watts peak pulse power (tp = 8/20μs)
Low clamping factor
Low leakage current
Low capacitance
Complies with the following standards:
IEC 61000-4-2 (ESD) Air-15kv, Contact-8kv
Applications
Cellular and Portable Electronics
Serial and Parallel Ports
Microprocessor Based Equipment
Notebooks, Desktops, Servers
Electrical characteristics per line@25℃(unless otherwise specified)
Parameter
Reverse stand-off voltage
Reverse Breakdown voltage
Reverse Leakage Current
Junction Capacitance
Junction Capacitance
Symbol
V
RWM
V
BR
I
R
C
j
C
j
Conditions
Min.
Typ.
Max.
12
Units
V
V
μA
pF
pF
I
T
= 1mA
V
RWM
= 9V T=25℃
V
R
=0V f = 1MHz
V
R
=3.0V
f = 1MHz
6.5
3.5
12.7
0.5
10
5.0
ESD Protector
1
