BCM7411
®
AVC/MPEG HIGH-DEFINITION DECODER
FEATURES
•
Multi-standard video decoding support for:
•
MPEG-2 MP@ML
•
MPEG-2 MP@HL
•
AVC HP@L3.0 for 480i
•
AVC HP@L3.2 720p
•
AVC HP@L4 1080i
•
AVC HP@L4.1 1080i for Blu-Ray and HD DVD
Multi-standard audio decoding
•
MPEG2 AAC-LC- Stereo and 5.1
•
MPEG4 AAC HE (High Quality)-Stereo (level 2) and
5.1 (level 4)
•
MP3 (MPEG1 layer 3)
•
Dolby
®
Digital Plus
•
Dolby Digital Plus to Dolby Digital transcode
Dual-stream decoding with independent program clock
reference (PCR) clock recovery
Two video output interfaces
•
BT.656
•
HD_DVI Interface for connection to BCM7038
•
HD or SD, with interlaced or progressive scanning
Video post-processing with scaling, 3:2 pull-down, clipping,
and padding
FUNCTIONAL COMPONENTS
•
•
•
•
•
•
•
H.264/MPEG-4 part 10 decoder
MPEG-2 decoder
Programmable audio decoder
Transport demultiplexer
HD-compatible digital video output ports
Multi-host control/status interface
DDR SDRAM controller
•
APPLICATIONS
•
•
•
•
Digital cable, satellite, terrestrial, IP, and DSL set-tops
HD DVD players
DVR (playback)
Portable multimedia players
•
•
•
Block Diagram
Control/Status
16-bit I/O
32-bit DDR
SDRAM
PCI 2.2
GPIO/SPI
Program I/O
DRAM Controller
PCI Interface
AVC High Profile
MPEG2 SD/HD
Decoder
Two Transport inputs
Transport
Processor
Programmable
Audio
Decoder
HD/SD
Video Scaler
HD_DVI out
656 out
Audio
Output
SPDIF
I2S x 2
OVERVIEW
Video Decoder Block Diagram
CABAC
H.264
Programmable
Parser
CAVLC
32-Bit
RISC
MPEG-2
VLC
Motion
Compensation
H.264 Inverse
Transform
Spatial
Prediction
H.264 or
MPEG-2
Coded
Stream
Stream
Input
Buffer
Image Reconstruction
Video
Output
MPEG-2
Programmable
Parser
MPEG-2 Inverse
Transform
H.264
Deblock
Digital Video
Output
The BCM7411 introduces the advantages of the H.264 video compression
algorithm to today’s advanced consumer and broadcast applications. The
BCM7411 is a dual-channel AVC/MPEG-2 decoder chip capable of full HD real-
time decoding.
Broadcom’s H.264 Compression Advantage™ architecture provides three times
the compression power of MPEG-2. Systems incorporating the BCM7411 have
superior image quality, improved system performance, and larger storage
capacity with the reduced bit rates of H.264—also known as MPEG-4 Advanced
Video Coding (AVC). The BCM7411 fully supports the MPEG-2 standard, so
that compatibility with existing media can be maintained.
The BCM7411 supports the following decoding operations:
•
•
1 HD (MPEG-2 or H.264) in real-time
2 SD streams (MPEG-2 or H.264) in real-time
Transport/Program Stream Demultiplexer
The BCM7411 accepts transport or program streams depending on the preferred
application, and parses the incoming video, audio, and private data for decoding.
The BCM7411 monitors PCR information in the transport stream to adjust the
frequency of an external VCXO oscillator.
Digital Video Output Ports
The BCM7411 provides configurable digital video output ports for a glueless
interface to the BCM7038 or to a variety of video DACs. The outputs may be
configured for BT656 and HD-DVI.
System Control/Status Interface
The BCM7411 is intended for use as a peripheral system and requires a
controlling agent to configure and monitor its operation. The following interfaces
are supported:
•
•
•
PCI 32-bit interface
Generic 16-bit host interface
SPI serial and GPIO interfaces
The H.264 Advantage
The H.264 coding standard incorporates innovations and techniques developed
over decades of worldwide research into video compression. The algorithm
produces results far superior to the preceding MPEG standards. H.264 derives
much of its performance gain from complex motion estimation techniques,
integration of an in-loop deblocking filter, and brand-new spatial prediction
operations.
BCM7411 Specifications
Parameter
Value
1.2
2.0
3.3
2.0
0 to 70
–30 to +125
Unit/Description
V
V
V
W
°C
°C
H.264 Support
•
•
•
•
•
•
•
•
Complies with the ISO/IEC 14496-10 specification
Decoder support for AVC High Profile streams up to level 4.1 with a 30 Mbps
maximum encoded bit rate restriction
I, B, and P slices
CABAC and CAVLC entropy decoding
Field/frame and picture adaptive decoding
Macroblock adaptive field/frame decoding
All intrablock and interblock sizes
Resolutions supported: QCIF up to 1920 × 1088
Logic supply
SDRAM I/O supply
I/O supply
Maximum power dissipation
Operating temperature
Storage temperature
Package Information
Package type
Package size
336-pin
27 × 27
Ball grid array
mm
MPEG-2 Support
The BCM7411 complies with the ISO/IEC 13818-2 specification and supports
Main Profile up to high level at 125 Mbps.
