CAPACITORS
For general purpose
Wide CV value range
ALUMINIUM ELECTROLYTIC STANDARD RADIAL CEBM
SECTION 1
Life 2000 hours at +85°C
Safety vent construction products
RANGE
V
µF
0.1
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
2200
3300
4700
6800
10000
15000
6.3
øxl/mm
6.3x11
8x11.5
10x12.5
12.5x20
12.5x20
16x25
16x25
16x31.5
18x35.5
10
øxl/mm
5x11
6.3x11
8x11.5
8x11.5
10x16
12.5x20
12.5x25
16x25
16x31.5
18x35.5
18x35.5
16
øxl/mm
6.3x11
8x11.5
8x11.5
10x12.5
10x20
12.5x25
16x25
16x31.5
18x32
18x35.5
25
øxl/mm
5x11
6.3x11
8x11.5
10x12.5
10x16
12.5x20
16x25
16x31.5
18x35.5
18x35.5
35
øxl/mm
5x11
6.3x11
8x11.5
10x12.5
10x16
10x20
12.5x25
16x31.5
18x35.5
18x35.5
50
øxl/mm
5x11
6.3x11
6.3x11
8x11.5
10x16
10x20
12.5x20
16x25
16x34.5
18x35.5
63
øxl/mm
5x11
6.3x11
6.3x11
8x11.5
10x12.5
10x20
12.5x20
12.5x25
16x31.5
22x40
100
øxl/mm
5x11
5x11
5x11
5x11
5x11
6.3x11
8x11.5
10x12.5
10x16
12.5x20
16x25
16x25
16x31.5
18x40
160
øxl/mm
6.3x11
6.3x11
6.3x11
8x11.5
8x11.5
10x12.5
10x20
12.5x20
12.5x25
16x25
18x35.5
200
øxl/mm
6.3x11
6.3x11
6.3x11
8x11.5
10x12.5
10x16
10x20
12.5x25
12.5x25
16x31.5
22x35.5
250
øxl/mm
5x11
5x11
6.3x11
6.3x11
8x11
8x11
10x16
10x16
10x20
12.5x25
12.5x25
16x31.5
400
øxl/mm
6.3x11
6.3x11
6.3x11
6.6.3x11
8x11.5
8x11.5
10x16
10x20
12.5x20
16x25
16x31.5
18x35.5
450
øxl/mm
6.3x11
6.3x11
6.3x11
6.3x11
8x11
10x16
10x20
12.5x20
12.5x25
16x31.5
18x35.5
18x40
Sizes may reduce as technology continually improves.
ORDERING INFORMATION
CEBM
Range
100
Capacitance
µF
16
Voltage
V
TA
Options:
TA = Tape/Ammo-box
Blank = Loose
CRxx = Cropped to xxMM
TA = 5mm pitch, e.g. TA 2mm = 2mm pitch
33
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
CAPACITORS
ALUMINIUM ELECTROLYTIC STANDARD RADIAL CEBM
SPECIFICATION
Item
Operating Temperature Range
Rated Working Voltage Range
Nominal Capacitance Range
Capacitance Tolerance
Leakage Current
tan ∂
Ripple Current
Low Temperature Characteristics
Impedance
High Temperature Loading
Shelf Life
Performance Characteristics
-25 to +85°C
160 to 450V DC
0.47 to 220µF
SECTION 1
-40 to +85°C
6.3 to 100V DC
0.47 to 15000µF
± 20% (120Hz, +20°C)
l ≤ 0.01CV or 3[µA] after 2 minutes
l ≤ 0.06CV [µA] after 2 minutes
whichever is greater measured with
application of rated working voltage at +20°C
rated working voltage applied at +20°C
Working voltage [V]
6.3 10
16
25
35
50
63
100
tan ∂ (max.)
0.22 0.19
0.16
0.14
0.12
0.10
0.09 0.08
Working voltage [V] 160 200
250
400
450
tan ∂ (max.)
0.16 0.18
0.18
0.20 0.20
(120Hz, +20°C) For capacitance value > 1000µF, add 0.02 per extra 1000µF
Refer to standard products table (120Hz, +85°C)
Correction factor for frequency
Frequency [Hz]
50/60 120
1K
10K
Correction factor (Multiplier) 0.7
1
1.3
1.7
Impedance ratio max. at 120Hz
Working voltage [V]
6.3 10
16
25
35
50
63
100
-25°C/+20°C
4 3
2
2
2
2
2
2
-40°C/+20°C
8 6
4
4
3
3
3
3
Working voltage [V] 160 200
250
400
450
-25°C/+20°C
2 2
3
15
15
For capacitance value > 1000µF,
Add 0.5 per extra 1000µF for -25°C/+25°C.
Add 1.0 per extra 1000µF for -40°C/+20°C.
Maximum C-Z (rated cap-[µF] x Impedance [Ω]) value at 10KHz
Working voltage [V]
6.3 10
16
25
35
50
63
100
C-Z max. at +20°C
220 160
125
90
80
60
55
50
C-Z max. at -25°C
3000 1900 1300 800
650
560
500
450
Working voltage [V] 160 200
250
450
C-Z max. at +20°C
100 140
150
270
C-Z max. at -25°C
2400 2500 3100
12000
Test conditions
Duration
2000 hours
Ambient temperature
+85°C
Applied voltage
Rated DC working voltage
Post test requirements at +20°C
Leakage current
≤ Initial specified value
Capacitance change
≤ ± 20% of initial measured value
tan ∂
≤ 150% of initial specified value
Test conditions
Duration
500 hours
Ambient temperature
+85°C
Applied voltage
(None)
Post test requirements at +20°C.
Same limits for high temperature loading.
34
