Telefon: +49 (0) 6135 931069

Telefax: +49 (0) 6135 931070

www.peak-electronics.de

info@peak-electronics.de

M1 SERIES

PN6CU-XXXXE 1KV ISOLATED 1W UNREGULATED SINGLE OUTPUT SIP7

Available Inputs:

5, 12, 24 and 48 VDC

Available Outputs:

3.3, 5, 7.2, 12, 15 and 18 VDC

Other specifications please enquire.

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Derating

Humidity

Cooling

Physical Characteristics

Dimensions SIP

Weight

Case material

+/- 10 %

Capacitors

1000 VDC

1 mA

Ohm

60 pF typ.

+/- 5 %, max.

75 mV p-p, max.

Momentary

+/- 1,2 % / 1,0 % of Vin

+/- 8 %, load = 20 ~ 100 %

+/- 0,02 % / °C

70 % to 85 %

125 KHz, typ.

- 40° C to + 85° C

- 55 °C to + 125 °C

See graph

Up to 90 %, non condensing

Free air convection

19,50 x 6,00 x 9,50 mm

0,76 x 0,24 x 0,37 inches

2 g, 3 g for the 48 VDC variants

Non conductive black plastic

Samples of Partnumbers

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

PN6CU-0505E

PN6CU-0512E

PN6CU-1205E

PN6CU-1212E

PN6CU-243R3E

PN6CU-2405E

PN6CU-2412E

PN6CU-4805E

PN6CU-4812E

266

254

119

104

3,3

200

303

200
