CYStech Electronics Corp.
30V N-CHANNEL Enhancement Mode MOSFET
Spec. No. : C427N3
Issued Date : 2008.05.16
Revised Date :
Page No. : 1/7
MTN3K14N3
Features
•
V
DS
=30V
R
DS(ON)
=39m
Ω
@V
GS
=10V, I
D
=2A
R
DS(ON)
=57m
Ω
@V
GS
=4.5V, I
D
=2A
•
Low on-resistance
•
High speed : ton=24ns(typ.), toff=19ns(typ.)
•
Pb-free package
Equivalent Circuit
MTN3K14N3
Outline
SOT-23
D
G：Gate
S：Source
D：Drain
S
G
Absolute Maximum Ratings
(Ta=25°C)
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
Pulsed Drain Current
Maximum Power Dissipation
Linear Derating Factor
Thermal Resistance, Junction to Ambient
Operating Junction and Storage Temperature
Symbol
V
DS
V
GS
I
D
I
DM
P
D
R
th, j-a
Tj, Tstg
Limits
30
±20
4
(Note 1)
8
(Note 2 & 3)
1.38
0.01
90
(Note 1)
-55 ~ +150
Unit
V
V
A
A
W
W/°C
°C/W
°C
Note : 1. Surface mounted on 1 in² copper pad of FR4 board; 270°C/W when mounted on min. copper pad
2. Pulse width limited by maximum junction temperature
3. Pulse width≤300μs, duty cycle≤2%
MTN3K14N3
CYStek Product Specification
CYStech Electronics Corp.
Spec. No. : C427N3
Issued Date : 2008.05.16
Revised Date :
Page No. : 2/7
Electrical Characteristics (Tj=25°C, unless otherwise specified)
Symbol
Static
BV
DSS
V
GS(th)
I
GSS
I
DSS
*R
DS(ON)
*G
FS
Dynamic
Ciss
Coss
Crss
*t
d(ON)
*t
r
*t
d(OFF)
*t
f
*Qg
Source-Drain Diode
*V
SD
Min.
30
1.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Typ.
-
-
-
-
-
-
-
-
6.4
460
62
106
24
15
19
6
5.0
-
Max.
-
2.5
±100
1
10
39
57
67
-
-
-
-
-
-
-
-
-
1.2
Unit
V
V
nA
μA
μA
mΩ
S
Test Conditions
V
GS
=0, I
D
=250μA
V
DS
=V
GS
, I
D
=250μA
V
GS
=±20V, V
DS
=0
V
DS
=30V, V
GS
=0
V
DS
=24V, V
GS
=0, Tj=55°C
I
D
=2A, V
GS
=10V
I
D
=2A, V
GS
=4.5V
I
D
=2A, V
GS
=4.0V
V
DS
=5V, I
D
=2A
pF
V
DS
=15V, V
GS
=0, f=1MHz
V
DS
=15V, I
D
=2A,
V
GS
=4V, R
G
=10
Ω
V
DS
=24V, I
D
=4A, V
GS
=4V
V
GS
=0V, I
S
=1.2A
*Pulse Test : Pulse Width
≤300μs,
Duty Cycle≤2%
ns
nC
V
Ordering Information
Device
MTN3K14N3
Package
SOT-23
(Pb-free)
Shipping
3000 pcs / Tape & Reel
Marking
3K14
MTN3K14N3
