SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 394, REV. A
SHD126036
ULTRA LOW REVERSE LEAKAGE POWER SCHOTTKY RECTIFIER
Very Low Voltage Drop
DESCRIPTION:
200 VOLT, 3.0 AMP, POWER SCHOTTKY RECTIFIER IN A HERMETIC TO-257 PACKAGE.
ALL RATINGS ARE @ T
C
= 25
°C
UNLESS OTHERWISE SPECIFIED.
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
SYMBOL
PIV
I
O
I
FSM
MAX.
200
3.0
55
UNITS
Volts
Amps
Amps
MAXIMUM DC OUTPUT CURRENT (With Cathode Maintained @ T
C
=100
O
C)
MAXIMUM NONREPETITIVE FORWARD SURGE CURRENT
(t = 8.3ms, Sine) (per leg)
MAXIMUM JUNCTION CAPACITANCE (V
r
=5V) (per leg)
MAXIMUM THERMAL RESISTANCE (Junction to Mounting Surface)
(per leg)
MAXIMUM OPERATING/JUNCTION TEMPERATURE RANGE
MAXIMUM STORAGE TEMPERATURE RANGE
C
T
R
θJC
60
9.2
pF
°C/W
Top
Tstg
-65 to
+ 200
-65 to
+ 175
°C
°C
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP, Pulsed (I
f
= 3.0 Amps) (per leg)
T
J
= 25
°C
T
J
= 125
°C
MAXIMUM REVERSE CURRENT (I
r
@ 200V PIV) (per leg)
T
J
= 25
°C
T
J
= 125
°C
REVERSE RECOVERY TIME
t
rr
I
r
0.025
0.20
9.0
ns
mA
V
f
1.02
0.86
Volts
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (516) 586-7600
•
FAX (516) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SHD126036
SENSITRON
DATA SHEET 394, REV. A
SINGLE
MECHANICAL DIMENSIONS: In Inches / mm
.150 (3.81
Dia.
.140 3.56)
.420 (10.67
.410 10.41)
.200 (5.08
.190 4.82)
.045 (1.14
.035 0.89)
1
2
3
.537 (13.64
.527 13.39)
1.132 (28.75
1.032 26.21)
.665 (16.89
.645 16.38)
.430 (10.92
.410 10.41)
1
2
3
.035 (0.89
.025 0.63)
3 Places
.100(2.54) BSC
2 Places
.120(3.05) BSC
TO-257
PINOUT TABLE
PIN 2
ANODE
PIN 3
ANODE
TYPE
SINGLE RECTIFIER
PIN 1
CATHODE
Typical Forward Characteristics
Instantaneous Reverse Current - I
R
(mA)
10
0
Typical Reverse Characteristics
200 °C
175 °C
150 °C
10
-2
10
-1
10
0
200 °C
175 °C
125 °C
100 °C
75 °C
Instantaneous Forward Current - I
F
(A)
10
-3
10
-4
10
-1
50 °C
10
-5
25 °C
0
40
80
120
160
200
Reverse Voltage - V
R
(V)
240
125 °C
25 °C
Junction Capacitance - C
T
(pF)
10
-2
Typical Junction Capacitance
60
45
30
15
0
0
40
80
120
160
200
Reverse Voltage - V
R
(V)
240
10
-3
0.0
0.2
0.4
0.6
0.8
1.0
Forward Voltage Drop - V
F
(V)
•
