BAS16T
Surface Mount Switching Diodes
P b
Lead(Pb)-Free
Features:
* Ultra-Small Surface Mount Package
* Fast
switching Speed
* For General Purpose Switching Applications
* High Conductance
SWITCHING DIODES
150
mAMPERES
75
VOLTS
3
1
2
Mechanical Data:
* Terminals: Solderable per MIL-STD-202, Method 208
* Polarity: See Diagrams Page.2
* Marking: See Diagrams Page.2
* Weight: 0.002 grams (approx)
SOT-523(SC-75)
SOT-523 Outline Dimensions (SC-75)
SC-75
B
C
Unit:mm
A
TOP VIEW
D
E
G
H
K
J
L
M
Dim
A
B
C
D
E
G
H
J
K
L
M
Min
0.30
0.70
1.45
-
0.15
0.80
1.40
0.00
0.70
0.37
0.10
Max
0.50
0.90
1.75
0.50
0.40
1.00
1.80
0.10
1.00
0.48
0.25
http://www.weitron.com.tw
WEITRON
1/3
06-Sep-10
BAS16T
Maximum Ratings
Characteristic
Non-Repetitive Peak reverse voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current
Average Rectified Output Current
Peak Forward Surge Current @t=1.0µS
@t=1.0S
Power Dissipation
Thermal Resistance
Junction temperature
Storage Temperature Range
(T
A
=25°C Unless otherwise noted)
Symbol
V
RM
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
I
FSM
Pd
R
θJA
T
j
T
STG
Value
100
75
53
300
150
2.0
1.0
200
625
150
-65 to + 150
Unit
V
V
V
mA
mA
A
mW
˚C/W
°C
°C
Electrical Characteristics
Characteristic
Reverse Breakdown Voltage
IR=1µA
Forward Voltage
IF=1.0mA
IF=10mA
IF=50mA
IF=150mA
Total Capacitance
V
R
=0V, f=1.0MHz
Reverse Current
V
R
=75V
V
R
=20V
Reverse Recover Time
I
F
=I
R
=10mA, I
rr
=0.1 x I
R
, R
L
=100Ω
(TA=25˚C Unless otherwise noted)
Symbol
V
(BR)R
Min
75
Max
-
715
855
1000
1250
2
1.0
0.025
4.0
Unit
V
V
F
-
mV
C
T
I
R
Trr
-
-
-
PF
µA
nS
Device Marking
Item
BAS16T
Marking
A2
Eqivalent Circuit diagram
3
1
http://www.weitron.com.tw
WEITRON
2/3
06-Sep-10
