SHANGHAI SUNRISE ELECTRONICS CO., LTD.
GBPC15005 THRU GBPC1510
SINGLE PHASE GLASS
PASSIVATED BRIDGE RECTIFIER
VOLTAGE: 50 TO 1000V CURRENT: 15A
FEATURES
• Glass passivated junction chip
• Surge overload rating: 300 A peak
• Low profile design
• 1/4" universal fasten terminal
and
φ.04"
lead - wire available
• High temperature soldering guaranteed:
250
o
C/10sec/0.375"(9.5mm) lead length
at 5 lbs tension
TECHNICAL
SPECIFICATION
GBPC15
GBPC15W
MECHANICAL DATA
• Polarity: Polarity symbol marked on body
• Mounting position: Hole thru for
#
10 screw
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Single-phase, half-wave, 60Hz, resistive or inductive load rating at 25
o
C, unless otherwise stated, for capacitive load,
derate current by 20%)
RATINGS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(T
c
=55
o
C)
Peak Forward Surge Current (8.3ms single
half sine-wave superimposed on rated load)
Maximum Instantaneous Forward Voltage
(at forward current 7.5A)
Maximum DC Reverse Current
T
a
=25
o
C
(at rated DC blocking voltage)
o
T
a
=100 C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
GBPC GBPC GBPC GBPC GBPC GBPC GBPC
UNITS
15005 1501 1502 1504 1506 1508 1510
50
100
200
400
600
800 1000 V
35
70
140
280
420
560
700
V
50
100
200
400
600
800 1000 V
15
300
1.1
10.0
500
-55 to +150
A
A
V
µA
µA
o
Storage and Operating Junction Temperature
T
STG
,T
J
Note:
Suffix "W" for wire type
