BCM5364/BCM5364P
®
SENTRY 5 PRODUCT LINE: BCM5364/BCM5364P SECURED SWITCH PROCESSORS
FEATURES
•
The most highly integrated access security processors
•
5-port 10/100 Ethernet switch with integrated PHY (TX/FX)
•
IEEE 802.1Q (VLAN) support; IEEE 802.1P (4 Priority Queues
- CoS, QoS), DiffServ, ToS support; IEEE 802.1D (Spanning
Tree) support
•
802.1X protocols, IP multicast, IGMP snooping for video
streaming applications, broadcast suppression, and hosting of
multiple subnets
•
128-KB on-chip packet buffer
•
General purpose 200-MHz MIPS32™ Processor·
•
8 KB of instruction cache, 4 KB of data cache
•
Supports Linux
®
, VxWorks
®
operating systems
SUMMARY OF BENEFITS
•
System-on-a-chip solution offers optimal price/performance
ratio and form factor, low power dissipation, and fastest time
to market
•
Integration of managed five-port Fast Ethernet switch
•
Integration of MIPS32 CPU with silicon-proven IPSec
processor facilitates complete packet processing in one pass for
multiple policy-based packet routing and/or packet
transformations (firewall, NAT, VPN, QoS)
•
Enables advanced application development with industry-
standard operating systems/platforms/tools
•
Widely proliferated high-performance MIPS32 CPU enables
advanced application development with industry-standard
operating systems/platforms/tools
•
Extensive application software offered
•
NAT, filtering (IP, TCP), dynamic firewall, DMZ
•
Ethernet routing, static routing, DHCP server/client
•
Compatible with other Broadcom devices, enabling optimal
system-level form factor, costs, and power dissipation
•
BCM5364P supports PCI 2.2, 32-bit/33-MHz host/slave
interface
•
Supports four additional PCI devices in host mode
•
Extensive interface flexibility
•
Interface to flash memory (up to 32 MB)
•
Interface to SDRAM/DDRAM (up to 512 MB, 100 MHz)
•
GPIO, USB, UART interface
•
JTAG/EJTAG support
•
400-pin PBGA package
•
Low power, 1.8V core, 3.3V I/O operation
•
Linux Open Source application software support
•
Third-party software support
BCM5364/5364P-Based System Applications
BCM5364-Based Wired Home Router
SDRAM(32MB)
BCM5364P-Based Wireless Router
SDRAM (Up to 512 MB)
FLASH (Up to 64 MB)
TX/RX
Wireless MAC
PCI
FLASH (2 MB)
Clock (25 MHz)
BCM2050
BCM430X
BCM5364
BCM5365
BCM5364P
BCM5365
Clock (25 MHz)
Magnetics Magnetics Magnetics Magnetics
RJ-45
RJ-45
RJ-45
RJ-45
Magnetics Magnetics Magnetics Magnetics
RJ-45
RJ-45
RJ-45
RJ-45
Magnetics
RJ-45
Magnetics
RJ-45
DMZ
4-Port 10/100 LAN
10/100 WAN
4-Port 10/100 LAN
10/100 WAN
OVERVIEW
SDRAM I/F
GPIO
On-Chip Bus
USB
UART
FLASH
I/F
8-KB I-CACHE
4-KB D-CACHE
On-Chip Bus
On-Chip Bus
PCI 2.2
Host
(32-Bit/33-MHz)
200-MHz
MIPS32
Core
MMU
Symmetric Key
Engine
75 Mbps
On-Chip Bus
Ethernet MAC/MII
Ethernet
Switch
Controller
4-Port 10/100
LAN PHY
10/100
WAN PHY
128-KB
Packet Buffer
Note: PCI Interface Supported in 5365P Only
Broadcom's
BCM5364
and
BCM5364P,
two System-On-Chips, are the
most highly integrated access switch processor there are. The
BCM5364/BCM5364P
also features an on-chip, five-port 10/100
Ethernet switch with management features. This switch processor also
offers extensive processor and interface integration featuring an
integrated 200-MHz MIPS32™ core, UART, flash and SDRAM/
DDRAM interfaces. The
BCM5364P
also supports a PCI interface. Both
the devices support IPSec encryption and authentication in a single pass.
The integrated 200-MHz MIPS32™ core of the
BCM5364/BCM5364P
has a 2-way set-associative 8-KB instruction cache and a 4-KB data
cache The CPU includes the MMU, which enables support for various
RTOS.
The
BCM5364/BCM5364P
also supports interfaces that enable system-
level cost savings, a better form factor, and lower power dissipation. The
BCM5364/BCM5364P
supports up to 512 MB of SDRAM/DDRAM
and 64 MB of flash memory.
The
BCM5364P
also supports the PCI version 2.2, 32-bit/33-MHz host
interface, allowing enumeration of four external PCI peripherals as a
way to extend system functionality. The UART enables a glueless
interface to serial devices such as modems.
Broadcom provides its proven API and drivers for integration with third-
party application software. Broadcom also offers application software to
build complete system applications. Application software support
includes functions such as firewall (dynamic firewall, DMZ hosting,
filtering-IP/TCP, NAT/PAT), VPN (IKE engines, IPSec drivers and
API, PPTP-passthrough, PPPoE client-PAP and CHAP authentication),
QoS/CoS/ToS (static and dynamic Ethernet routing, VLAN tagging),
and many other features.
A single
BCM5364/BCM5364P
based platform is easy to reuse for
other types of access to market segment equipment ranging in throughput
performance from T1/E1 to 100 Mbps. This equipment includes wireless
and wired home/residential and SOHO firewall and VPN appliances,
wireless access points, and many types of customer premises equipment
(CPE) devices.
