AS8267 / AS8268
Single-Phase 2-Current Energy Measurement Integrated Circuits
with Microcontroller, RTC, Programmable Multi-Purpose I/Os,
LCD Driver and On-Chip FLASH Memory
DATA SHEET
1. Key Features
-
-
Mains current lead/lag status indication for
reactive energy measurement.
Low power battery operating mode for meter
reading when Mains voltage is not present.
AS8267: 20 x 4 segment LCDD
9 x multi-purpose I/O (MPIO)
AS8268: 24 x 4 segment LCDD
12 x multi-purpose I/O (MPIO)
Precision single-phase, one or two current input
energy measurement front-end including Sigma-
Delta modulators for A/D-conversion and digital
signal processor (DSP).
Low current consumption of 5mA, depending on
MCU activity.
Digital phase correction and selectable gain on
both current channels for use with two current
transformers (CT) or one CT and one shunt.
Power-supply monitor (PSM) for power-on reset
and reset when the supply voltage falls below a
defined threshold.
Customer programmable 8-bit 8051 compatible
microcontroller (MCU).
Programmable MCU clock for optional low
power operating conditions.
Highly reliable 32kBytes of non-volatile Flash
memory is provided on-chip for storage of both
program and data.
Program and data security is provided by
optional password and attack counter
protection.
2 x Universal Asynchronous Receiver /
Transmitters (UART) for external
communications such as programme download
and debugging.
Programmable watchdog timer (WDT) and
external system reset pin.
Real-time clock/calendar (RTC) with on-chip
digital calibration and separate battery supply
pin.
On-chip temperature sensor for optional
temperature compensation.
On-chip voltage reference (VREF) with small
temperature coefficient (15ppm/K typ.).
Low power 3.0 – 4.0MHz crystal oscillator.
SPI compatible interface for optional external
non-volatile EEPROM memory selectable up to
32kBytes.
-
-
-
-
-
2. General Description
The AS8267 / AS8268 are highly integrated CMOS
single-phase energy metering devices for fully
electronic LCD meter systems. The AS8267 /
AS8268 have been designed to ensure a meters
full compliance with the international Standards
IEC62052 and ANSI.
The AS8267 / AS8268 ICs include all the functions
required for conventional 1 current or 2-current
anti-tamper meters. The functions include precision
energy measurement, an 8-bit microcontroller unit
(MCU) with 32kBytes of Flash memory, an on-chip
Liquid Crystal Display driver (LCDD),
programmable multi-purpose Inputs/Outputs
(MPIO), a real time clock/calendar (RTC) for
complex tariff functions such as time-of-use or
maximum demand billing and a Serial Peripheral
Interface (SPI) for reading data from and writing
data to an optional external non-volatile memory
(EEPROM).
The AS8267 / AS8268 ICs have a dedicated energy
measurement front-end, which includes an analog
front-end and programmable Digital Signal
Processor (DSP) from which active energy, mains
voltage and mains current are provided. Reactive
and apparent energy can also be calculated.
The on-chip 8-bit 8051 compatible microcontroller
is freely programmable and provides user access to
the various functional blocks. The dedicated
Universal Asynchronous Receiver / Transmitter
(UART1) in the System Control block allows access
to various system functions and blocks. A second
UART (UART2) is also provided, which may for
example be used for debugging. The on-chip
memory includes 32kByte of highly reliable non-
volatile Flash program (and data) memory and
-
-
-
-
-
-
-
-
-
-
-
-
Revision 1.0, 19-Jun-07
Page 1 of 136
Data Sheet AS8267 / AS8268
1kByte volatile data memory. The meter system
designer also has the option of an additional
external EEPROM memory, which is selectable in
size from 1kByte to 32kByte (in binary steps).
Program and data stored in the on-chip non-volatile
Flash memory can be secured by password
protection, in addition to an attack counter which
‘locks’ access after 5 unauthorised attacks.
An on-chip programmable watchdog timer (WDT) is
available to automatically initiate a system reset if
a regular ‘hold-off’ signal is not detected.
The system timing and real time clock (RTC) has a
dedicated external battery supply pin (VDD_BAT),
enabling the oscillator and RTC to continue
operation during ‘power-down’. The RTC may be
digitally calibrated for oscillator frequency
accuracy.
The on-chip temperature sensor provides the meter
designer the option of temperature compensation
for any of the measured parameters or functional
blocks provided, over the full operating temperature
range of the device.
The LCD Driver (LCDD) block enables the display
of information provided by the microcontroller,
directly to the LCD. Two dedicated data register
banks are provided to simplify programming,
particularly in the case where scrolled display data
is required.
The programmable multi-purpose I/O pins (MPIO)
may be independently configured as inputs or
outputs. All the I/O pins are programmable for data
direction, pull-up/pull-down resistors and drive
strength (4mA/8mA). Typical functions may include
LED energy consumption pulse output, energy
direction and fault condition indication depending
on current 1 or current 2 being active for the
energy calculation, push button for display
scrolling, mains isolation relay control for
prepayment meters, optical interface etc.
An on-chip analog ground buffer (ABUF) and
voltage reference (VREF) ensures that no external
circuitry is required. A power-supply monitor (PSM)
provides a reset, when VDD falls below a safe
operating threshold.
A reset pin (RES_N) is available for external
system reset.
The AS8267 / AS8268 ICs are available in LQFP64
plastic package.
Revision 1.0, 19-Jun-07
Page 2 of 136
Data Sheet AS8267 / AS8268
3. Typical Application Circuit
3.3V
3.3V
+
+
LCD
3.3V
XIN XOUT
32
33
Low
Power
Oscillator
VDDA
7
Low
Power
Divider
13
VDDD
22
LBP0
LBP1
LBP2
LBP3
kWh
Vrms
Irms
37 38 39 40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
9
LSD0
LSD1
LSD2
LSD3
LSD4
LSD5
LSD6
LSD7
LSD8
LSD9
LSD10
LSD11
LSD12
LSD13
LSD14
LSD15
LSD16
LSD17
LSD18
LSD19
LSD20
LSD21
LSD22
LSD23
IO0
IO1
IO2
IO3
IO4
IO5
IO6
IO7
IO8
IO9
IO10
IO11
LED
DIRO
FAULT
VDD_BAT 31
RTC
System Timing & RTC
LOAD
I1P
3
Analog Front End
LCD
Driver
SDM
I1N
I2N
4
6
SDM
I2P
VP
5
1
DSP
MCU
SDM
VN
RES_N
2
34
I/Os
Examples
only
10
11
WDT
Temperature
Sensor
FLASH
Memory
Multi-
purpose
I/Os
12
15
16
17
18
19
26
27
28
Push-Button
Reference pulses
for calibration
AS8268 only
System
Control
UART1
23 S_N
20 MISO
24 MOSI
25 SC
SPI
29
TXD
VI
VO
30
RXD
3.3V
8
VSSA
14
VSSD
21
VSSD
EEPROM
S 1
Q
2
3.3V W 3
VSS
4
8 VCC 3.3V
HOLD 3.3V
7
6 C
5 D
+
GND
N
L
Figure 1:
Typical application circuit of the AS8267 / AS8268
