TRUMPower

D E SCR IPTION

130 WATT MEDICAL POWER ADAPTERS

TMP130 SERIES

(MDD+EMC)

The TMP130 series of AC/DC switching power

adapters are for 100 to 130 watts of continuous

output power. They are designed for medical

applications that require external power. The units

are enclosed in a 94V-1 rated polyphenylene-oxide

case with an IEC 320 inlet to mate with

interchangeable cord for world-wide use. An on/off

switch can be added at request. All models meet

CISPR 11 and FCC class B emission limits, and

comply with UL, CSA, IEC and CE requirements.

F EATU R E S

‧

In compliance with EN61000-3-2, EN61000-3-3 and

EN61000-1-1-2

‧

Optional output connectors

‧

Optional on/off sw itch

‧

Optional Power Fail Detect (PFD) signal

‧

100% burn-in at full load

‧

Auto-ranging input

‧

Input surge current protection

‧

O v e r v o l ta g e p r o t e c t i o n

‧

Thermal protection

S af e t y Sta nd ar d A pp ro va l s：

UL 2601-1

CSA C22.2 No. 601.1

INPUT SPECIFICATIONS

9 0 t o 1 3 2 VA C o r 1 8 0 t o 2 6 4 VA C

(auto-ranging)

Input frequency

：

47 to 63 Hz

Input current

：

3 . 0 A ( r m s ) f o r 11 5 VA C

1 . 7 A ( r m s ) f o r 2 3 0 VA C

L e a k a g e c u r r e n t

：

9 0 µ A m a x . @ 11 5 VA C , 6 0 H z

1 5 0 µ A m a x . @ 2 3 0 VA C , 5 0 H z

I n p u t v o l ta g e

：

TÜV EN60601-1

OUTPUT SPECIFICATIONS

Output voltage/current：

Total output power：

Ripple and noise：

Overvoltage protection：

See rating chart

130 watts maximum

1% peak to peak maximum

Provided on output: set at

112 – 132% of its nominal

output voltage

All outputs protected to

short circuit conditions

GENERAL SPECIFICATIONS

Switching frequency:

68 Khz ±8Khz

70% minimum on Vo

≥12V

Efficiency:

65% minimum on others

10 msec minimum at 115VAC

Hold-up time:

±0.5% maximum at full load

Line regulation:

15amps @115VAC, or 30amps

Inrush current:

@230VAC, at 25ºC and cold start

4000VAC from input to output

Withstand voltage:

1500VAC from input to ground

5000VAC from output to ground

400,000 hours minimum at full load

MTBF:

at 25ºC ambient, calculated per

MIL-HDBK-217F, excluding DC fan.

EMC Performance (EN60601-1-2: 2001)

EN55011:

Class B conducted, class B radiated

FCC:

Class B conducted, class B radiated

VCCI:

Class B conducted, class B radiated

EN61000-3-2:

Harmonic distortion, class A

EN61000-3-3:

Line flicker

EN61000-4-2:

ESD, ±8KV air and ±6KV contact

EN61000-4-3:

Radiated immunity, 3V/m for

80~2500MHz

EN61000-4-4:

Fast transient/burst, ±2KV

EN61000-4-5:

Surge, ±1KV diff, ±2KV com.

EN61000-4-6:

Conducted immunity, 3Vrms

EN61000-4-8:

Magnetic field immunity, 3A/m

EN61000-4-11:

Voltage dips, 30% reduction for

500ms, 60% reduction for 100ms and

>95% reduction for 10ms

Overcurrent protection：

Temperature coefficient：

All outputs ±0.04%/ºC

maximum

Transient response：

Maximum excursion of 4% or

better on all models,

recovering to 1% of final

value within 500µs after a

25% step load change

E N V IR O N M ENTA L SP E C IF ICATI O N S

Operating temperature:

Storage temperature：

Relative humidity：

Derating：

0ºC to +70ºC

-40ºC to +85ºC

5% to 95% non-condensing

Derate from 100% at +50ºC

linearly to 50% at +70ºC

Tumbler Technologies + TRUMPower

3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA

Phone: 408-988-6616

●

Fax: 408-988-6622

●

email: sales@trumpower.com

●

Website: www.TRUMPower.com
