SHARP BREAKDOWN, LOW LEAKAGE

LVA REGULATOR DIODES

LVA43A - LVA100A

•

Sharper breakdown

•

Lower leakage current characteristics in the 4 – 10 volt range

PART

NUMBER

NOMINAL

VOLTAGE

Vz @ Izt

(Vdc)

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

10.0

TEST

CURRENT

Izt

(mA)

MAX ZENER

IMPEDANCE

Zzt @ Izt

(OHMS)

100

MAX REVERSE

LEAKAGE CURRENT

(µAdc)

(Vdc)

4.0

1.5

4.0

2.0

0.1

2.0

0.05

3.0

0.05

4.0

0.05

5.0

0.01

6.0

0.01

6.5

0.01

8.0

0.01

9.0

MAX NOISE

DENSITY

250 µA

LVA43A

LVA47A

LVA51A

LVA56A

LVA62A

LVA68A

LVA75A

LVA82A

LVA91A

LVA100A

Package Style

Forward Voltage (Vf)

Noise Density (Nd)

Power Dissipation (Pd)

Operating Temperature (Topr)

Storage Temperature (Tstg)

Voltage Tolerance:

@ If= 200 mAdc

@ Iz = 250 µAdc

@ Ta = 25° C

Standard Device

Suffix A

Suffix B

DO-7

1.5 Vdc

4.0 µV /

√

400 mW

-65 to + 175° C

-65 to + 200° C

±10%

±5%

±2%

Noise Density measured from 1000 to 3000 Hz.

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558

-29-
