DSB05A30 Overview

0.2 A, 30 V, SILICON, SIGNAL DIODE, DO-35

Preview

Download Datasheet

View All

• 1N6677-1 AVAILABLE IN

PER MIL-PRF-19500/610

JAN, JANTX, JANTXV AND JANS

1N6675 thru 1N6677

and

DSB0.2A20 thru DSB0.2A40

and

DSB0.5A20 thru DSB0.5A40

• 0.2 AND 0.5 AMP SCHOTTKY BARRIER RECTIFIERS

• HERMETICALLY SEALED

• METALLURGICALLY BONDED

• DOUBLE PLUG CONSTRUCTION

MAXIMUM RATINGS - 0.2 AMP DEVICES

Operating Temperature: -65°C to +125°C

Storage Temperature: -65°C to +150°C

Average Rectified Forward Current: 0.2 AMP @TL = +100°C, =3/8”

Derating: 8.0 mA / °C above TL = +100°C, L = 3/8”

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified.

CDI

TYPE

NUMBER

WORKING PEAK

REVERSE

VOLTAGE

VRWM

VOLTS

1N6675

1N6676

1N6677

DSB0.2A20

DSB0.2A30

DSB0.2A40

MAXIMUM REVERSE

LEAKAGE CURRENT

AT RATED VOLTAGE

IR @ +25°C

IR @ +100°C

0.6

MAXIMUM

CAPACITANCE @

VR = 0 VOLTS

f =1.0 MHz

PICO FARADS

0.055 / 0.090

1.40 / 12.29

MAXIMUM FORWARD VOLTAGE

VF @ 20 mA VF @ 200 mA VF @ 630 mA

VOLTS

0.37

VOLTS

0.50

VOLTS

0.70

0.120 / 0.200

3.05 / 5.08

5.0

0.018 / 0.022

0.457 / 0.559

1.000

25.400

FIGURE 1

MAXIMUM RATINGS - 0.5 AMP DEVICES

Operating Temperature: -65°C to +125°C

Storage Temperature: -65°C to +150°C

Average Rectified Forward Current: 0.5 AMP @ +75°C

Derating: 6.67 mA / °C above +75°C

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified.

MAXIMUM

CAPACITANCE @

VR = 0 VOLTS

f =1.0 MHz

PICO FARADS

DESIGN DATA

CASE:

Hermetically sealed, DO-35

LEAD MATERIAL:

Copper clad steel

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJEC):

250 ˚C/W maximum at L = .375 inch

THERMAL IMPEDANCE: (Z

OJX): 20

˚C/W maximum

POLARITY:

Cathode end is banded.

MOUNTING POSITION:

Any

CDI

TYPE

NUMBER

WORKING PEAK

REVERSE

VOLTAGE

VRWM

VOLTS

MAXIMUM

FORWARD VOLTAGE

VF @ 0.1A

VOLTS

0.50

VF @ 0.5A

VOLTS

0.65

MAXIMUM REVERSE

LEAKAGE CURRENT

AT RATED VOLTAGE

IR @ +25°C

IR @ +100°C

1.0

10.0

DSB0.5A20

DSB0.5A30

DSB0.5A40

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
