B120/B - B160/B
1.0A SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Features
·
·
·
·
·
·
Guard Ring Die Construction for
Transient Protection
Ideally Suited for Automatic Assembly
Low Power Loss, High Efficiency
Surge Overload Rating to 30A Peak
For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Application
Lead Free Finish/RoHS Compliant (Note 3)
B
Dim
A
SMA
Min
2.29
4.00
1.27
0.15
4.80
0.10
0.76
2.01
Max
2.92
4.60
1.63
0.31
5.59
0.20
1.52
2.62
SMB
Min
3.30
4.06
1.96
0.15
5.00
0.10
0.76
2.00
Max
3.94
4.57
2.21
0.31
5.59
0.20
1.52
2.62
A
C
B
C
D
E
G
H
J
Mechanical Data
·
·
·
·
·
·
·
·
Case: SMA/SMB
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Lead Free Plating (Matte Tin Finish).
Solderable per MIL-STD-202, Method 208
e
3
Polarity: Cathode Band or Cathode Notch
Marking Information: See page 3
Ordering Information: See page 3
Approximate Weight: SMA 0.064 grams
SMB 0.093 grams
D
J
H
G
E
All Dimensions in mm
No Suffix Designates SMA Package
“B” Suffix Designates SMB Package
Maximum Ratings and Electrical Characteristics
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@ T
T
= 130°C
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
Forward Voltage
Peak Reverse Current
at Rated DC Blocking Voltage
Typical Total Capacitance (Note 2)
Typical Thermal Resistance Junction to Terminal (Note 1)
Operating and Storage Temperature Range
Notes:
@ T
A
= 25°C unless otherwise specified
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
RM
C
T
R
qJT
T
j,
T
STG
B120/B
20
14
B130/B
30
21
B140/B
40
28
1.0
30
B150/B
50
35
B160/B
60
42
Unit
V
V
A
A
@ I
F
= 1.0A
@ T
A
= 25°C
@ T
A
= 100°C
0.50
0.5
10
110
20
-65 to +150
0.70
V
mA
pF
°C/W
°C
1. Thermal Resistance: Junction to terminal, unit mounted on PC board with 5.0 mm
2
(0.013 mm thick) copper pads as heat sink.
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V DC.
3. RoHS revision 13.2.2003. High Temperature Solder Exemption Applied, see
EU Directive Annex Note 7.
DS13002 Rev. 13 - 2
1 of 3
www.diodes.com
B120/B-B160/B
ã
Diodes Incorporated
10
I
F
, INSTANTANEOUS FWD CURRENT (A)
I
O,
AVERAGE RECTIFIED CURRENT (A)
1.0
T
A
= +125°C
T
A
= +75°C
T
A
= +25°C
1.0
T
A
= -25°C
0.5
0
25
50
75
100
125
150
0.1
0.2
0.4
0.6
0.8
1.0
1.2
T
T
, TERMINAL TEMPERATURE (ºC)
Fig. 1 Forward Current Derating Curve
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
10
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics - B120/B thru B140/B
40
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
Single Half Sine-Wave
30
1.0
T
A
= +125ºC
20
T
A
= +25ºC
0.1
10
0.01
0
0.2
0.4
I
F
Pulse Width = 300 ms
0
1
10
NUMBER OF CYCLES AT 60 Hz
Fig. 4 Max Non-Repetitive Peak Fwd Surge Current
100
0.6
0.8
1.0
V
F
, INSTANTANEOUS FWD VOLTAGE (V)
Fig. 3 Typ. Forward Characteristics - B150/B thru B160/B
1000
T
j
= 25°C
f = 1 MHz
10,000
T
A
= +125°C
C
T
, TOTAL CAPACITANCE (pF)
1000
T
A
= +75°C
100
100
10
T
A
= +25°C
1
0.1
T
A
= -25°C
10
0.1
1
10
100
0.01
0
10
20
30
40
50
V
R
, REVERSE VOLTAGE (V)
Fig. 5 Typical Total Capacitance
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 6 Typical Reverse Characteristics, B120/B thru B140/B
DS13002 Rev. 13 - 2
2 of 3
www.diodes.com
B120/B-B160/B
10,000
1000
T
A
= +125°C
100
10
T
A
= +70°C
1
T
A
= +25°C
0.1
0
10
20
30
40
50
60
70
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 7 Typical Reverse Characteristics, B150/B thru B160/B
Ordering Information
(Note 4)
Device*
B1XX-13-F
B1XXB-13-F
Notes:
Packaging
SMA
SMB
Shipping
5000/Tape & Reel
3000/Tape & Reel
4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
* xx = Device type, e.g. B120-13-F (SMA package); B120B-13-F (SMB package).
Marking Information
B1X0 = Product type marking code, ex: B120 (SMA package)
B1X0B = Product type marking code, ex: B160B (SMB package)
= Manufacturers’ code marking
YWW = Date code marking
Y = Last digit of year ex: 2 for 2002
WW = Week code 01 to 52
YWW
B1X0(B)
Note: Device has a cathode band (as shown above) and may also have a cathode notch (as shown on Page 1).
