PPR
Small Size Polypropylene
Film Capacitors for High
Pulse Current Applications
Electronic Ballasts
High Voltage
High Current
High Pulse Current Applications
•
Snubber Capacitor for Energy Conversion
•
in Power Semiconductor Circuits.
•
•
SCR Commutation
•
•
TV Deflection Circuits
•
•
SMPS Protection Circuits
Operating Temperature Range
Capacitance Tolerance
WVDC
Rated Voltage
VAC
400
600
630
1000
-55˚C to +105˚C
+/- 10% at 1kHz, 20˚C
1600
650
2000
700
DC: For T>85°C voltage must be rated by 1.25% for every °C above 85°C
AC: For T>75°C voltage must be rated by 1.35% for every °C above 75°C
Freq (kHz)
Dissipation Factor
(max) at 20˚C.
1
10
100
Insulation Resistance
@20˚C(<70% RH)
for 1 minute at 100VDC
Dielectric Strength
Load Life
C≤0.33µF
C>0.33µF
C≤0.1µF
.03%
.05%
.15%
0.1µF>C≤1µF
.03%
.06%
-
≥100,000MΩ
≥30,000MΩ
x µF
160% of rated VDC for 2 seconds at 20°C between leads
2000 hours at 85°C±2°C with 125% of rated voltage
Capacitance change
Dissipation Factor
Insulation Resistance
Self inductance
Capacitance drift
Temperature Coefficient
Reliability
fit=1x10
9
Failures/component hours.
Applied Voltage=0.5xVDC
Temperature=+40°C±2°C
Dielectric
Electrodes
Construction
Leads
Coating
≤2%
change from initial value
≤0.1%
at 10kHz and 25°C for C≤1µF
≤0.1%
at 1kHz and 25°C for C>1µF
≥50%
of specified value
<1nH/mm of capacitor lead spacing.
<0.5% up to 40°C after 2 years
-200ppm/˚C +/- 100ppm/˚C
≤1FIT
Capacitance change
Dissipation Factor
Insulation Resistance
≤10%
change from initial value
>2x initial specified value.
<0.005x initial specified value.
Polypropylene
Vacuum deposited metal layers
Extended double metallized carrier film, internal series
connections and metallized film.
Tinned copper leads.
Solvent resistant plastic box (UL 94V-1) with epoxy end fills (UL 94V-0)
C>1µF
.04%
-
-
®
3757 W. Touhy Ave., Lincolnwood, IL 60712 • (847) 675-1760 • Fax (847) 673-2850 • www.illcap.com
192
PPR
WVDC
(VAC)
630
(400)
1,000
(600)
Small Size
Polypropylene Film
Capacitor for High Pulse
Current Applications
PHYSICAL DIMENSIONS
µF
1,600
(650)
2,000
(700)
18x11x5
18x11x5
18x11x5
18x11x5
18x11x5
18x12x6
18x11x5
18x12x6
18x13.5x7.5
18x14.5x8.5
26.5x15x6
18x16x10
26.5x15x6
26.5x17x8.5
32x17x9
26.5x18.5x10
32x17x9
26x5x22x13
32x20x11
32x22x13
18x13.5x7.5
18x14.5x8.5
26.5x15x6
26.5x16x7
26.5x17x8.5
26.5x18.5x10
32x17x9
26.5x22x13
32x20x11
32x22x13
32x28x14
32x33x18
18x12x6
18x13.5x7.5
18x14.5x8.5
26.5x15x6
26.5x16x7
26.5x18.5x10
32x17x9
26.5x20x11
32x17x9
26.5x22x13
32x20x11
32x24.5x15
32x33x18
32x33x18
42.5x28x17
32x37x22
42.5x30x22
42.5x37x28
42.5x45x30
18x12x6
18x13.5x7.5
18x13.5x7.5
18x16x10
26.5x15x6
26.5x16x7
26.5x17x8.5
32x17x9
26.5x18.5x10
32x17x9
26.5x22x13
32x20x11
32x22x13
32x28x14
32x33x18
42.5x28x17
32x37x22
42.5x30x22
42.5x37x28
42.5x37x28
42.5x45x30
32x24.5x15
32x33x18
42.5x28x17
32x37x22
42.5x30x22
42.5x37x28
42.5x45x30
42.5x45x30
32x37x22
42.5x30x22
42.5x37x28
42.5x37x28
42.5x45x30
0.0022
0.0033
0.0047
0.0068
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.56
0.68
1
1.5
1.8
2.2
3.3
3.9
Convert to inches, divide by 25.4
LxHxT (mm)
L
T
H
L
18
26.5
32
42.5
S
15
22.5
27.5
37.5
d
0.8
0.8
0.8
1.0
LL
5.0±1.0 5.0±1.0 30±5.0 30±5.0
d
LL
Power Films
S ± 0.4
®
3757 W. Touhy Ave., Lincolnwood, IL 60712 • (847) 675-1760 • Fax (847) 673-2850 • www.illcap.com
193
