TIC206 SERIES
SILICON TRIACS
Copyright © 1997, Power Innovations Limited, UK
DECEMBER 1971 - REVISED MARCH 1997
q
q
q
q
q
Sensitive Gate Triacs
4 A RMS
Glass Passivated Wafer
400 V to 800 V Off-State Voltage
Max I
GT
of 5 mA (Quadrants 1 - 3)
MT1
MT2
G
1
2
3
TO-220 PACKAGE
(TOP VIEW)
Pin 2 is in electrical contact with the mounting base.
MDC2ACA
absolute maximum ratings
over operating case temperature (unless otherwise noted)
RATING
TIC206D
Repetitive peak off-state voltage (see Note 1)
TIC206M
TIC206S
TIC206N
Full-cycle RMS on-state current at (or below) 85°C case temperature (see Note 2)
Peak on-state surge current full-sine-wave (see Note 3)
Peak on-state surge current half-sine-wave (see Note 4)
Peak gate current
Peak gate power dissipation at (or below) 85°C case temperature (pulse width
≤
200
µs)
Average gate power dissipation at (or below) 85°C case temperature (see Note 5)
Operating case temperature range
Storage temperature range
Lead temperature 1.6 mm from case for 10 seconds
I
T(RMS)
I
TSM
I
TSM
I
GM
P
GM
P
G(AV)
T
C
T
stg
T
L
V
DRM
SYMBOL
VALUE
400
600
700
800
4
25
30
±0.2
1.3
0.3
-40 to +110
-40 to +125
230
A
A
A
A
W
W
°C
°C
°C
V
UNIT
NOTES: 1. These values apply bidirectionally for any value of resistance between the gate and Main Terminal 1.
2. This value applies for 50-Hz full-sine-wave operation with resistive load. Above 85°C derate linearly to 110°C case temperature at
the rate of 160 mA/°C.
3. This value applies for one 50-Hz full-sine-wave when the device is operating at (or below) the rated value of on-state current.
Surge may be repeated after the device has returned to original thermal equilibrium. During the surge, gate control may be lost.
4. This value applies for one 50-Hz half-sine-wave when the device is operating at (or below) the rated value of on-state current.
Surge may be repeated after the device has returned to original thermal equilibrium. During the surge, gate control may be lost.
5. This value applies for a maximum averaging time of 20 ms.
electrical characteristics at 25°C case temperature (unless otherwise noted)
PARAMETER
I
DRM
Repetitive peak
off-state current
Peak gate trigger
current
V
D
= rated V
DRM
V
supply
= +12 V†
I
GTM
V
supply
= +12 V†
V
supply
= -12 V†
V
supply
= -12 V†
V
supply
= +12 V†
V
GTM
Peak gate trigger
voltage
V
supply
= +12 V†
V
supply
= -12 V†
V
supply
= -12 V†
† All voltages are with respect to Main Terminal 1.
TEST CONDITIONS
I
G
= 0
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
R
L
= 10
Ω
T
C
= 110°C
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
t
p(g)
> 20
µs
0.5
-1.5
-2
3.6
0.7
-0.7
-0.8
0.8
MIN
TYP
MAX
±1
5
-5
-5
10
2
-2
-2
2
V
mA
UNIT
mA
PRODUCT
INFORMATION
Information is current as of publication date. Products conform to specifications in accordance
with the terms of Power Innovations standard warranty. Production processing does not
necessarily include testing of all parameters.
1
TIC206 SERIES
SILICON TRIACS
DECEMBER 1971 - REVISED MARCH 1997
electrical characteristics at 25°C case temperature (unless otherwise noted) (continued)
PARAMETER
V
TM
I
H
I
L
dv/dt
dv/dt
(c)
Peak on-state voltage
Holding current
Latching current
Critical rate of rise of
off-state voltage
Critical rise of
commutation voltage
I
TM
= ±4.2 A
V
supply
= +12 V†
V
supply
= -12 V†
V
supply
= +12 V†
V
supply
= -12 V†
V
DRM
= Rated V
DRM
V
DRM
= Rated V
DRM
TEST CONDITIONS
I
G
= 50 mA
I
G
= 0
I
G
= 0
(see Note 7)
I
G
= 0
I
TRM
= ±4.2 A
T
C
= 110°C
T
C
= 85°C
±1
±50
±1.3
±2.5
(see Note 6)
Init’ I
TM
= 100 mA
Init’ I
TM
= -100 mA
MIN
TYP
±1.3
2
-4
MAX
±2.2
15
-15
30
-30
UNIT
V
mA
mA
V/µs
V/µs
† All voltages are with respect to Main Terminal 1.
NOTES: 6. This parameter must be measured using pulse techniques, t
p
=
≤
1 ms, duty cycle
≤
2 %. Voltage-sensing contacts separate from
the current carrying contacts are located within 3.2 mm from the device body.
7. The triacs are triggered by a 15-V (open circuit amplitude) pulse supplied by a generator with the following characteristics:
R
G
= 100
Ω,
t
p(g)
= 20
µs,
t
r
=
≤
15 ns, f = 1 kHz.
thermal characteristics
PARAMETER
R
θ
JC
R
θ
JA
Junction to case thermal resistance
Junction to free air thermal resistance
MIN
TYP
MAX
7.8
62.5
UNIT
°C/W
°C/W
TYPICAL CHARACTERISTICS
GATE TRIGGER CURRENT
vs
TEMPERATURE
1000
V
supply
I
GTM
I
GT
- Gate Trigger Current - mA
+
+
-
-
+
-
-
+
TC05AA
GATE TRIGGER VOLTAGE
vs
TEMPERATURE
10
V
supply
I
GTM
V
GT
- Gate Trigger Voltage - V
+
+
-
-
+
}
-
-
}
+
TC05AB
V
AA
= ± 12 V
R
L
= 10
Ω
t
w(g)
= 20 µs
V
AA
= ± 12 V
R
L
= 10
Ω
t
w(g)
= 20 µs
100
10
1
1
0·1
-60
-40
-20
0
20
40
60
80
100
120
0·1
-60
-40
-20
0
20
40
60
80
100
120
T
C
- Case Temperature - °C
T
C
- Case Temperature - °C
Figure 1.
Figure 2.
PRODUCT
INFORMATION
2
TIC206 SERIES
SILICON TRIACS
DECEMBER 1971 - REVISED MARCH 1997
TYPICAL CHARACTERISTICS
HOLDING CURRENT
vs
CASE TEMPERATURE
100
V
AA
= ± 12 V
I
H
- Holding Current - mA
I
G
= 0
Initiating I
TM
= 100 mA
10
V
GF
- Gate Forward Voltage - V
TC05AD
GATE FORWARD VOLTAGE
vs
GATE FORWARD CURRENT
10
TC05AC
1
1
V
supply
+
-
0·1
I
A
= 0
T
C
= 25 °C
0·1
-60
-40
-20
0
20
40
60
80
100
120
QUADRANT 1
0·01
0·0001
0·001
0·01
0·1
1
T
C
- Case Temperature - °C
I
GF
- Gate Forward Current - A
Figure 3.
Figure 4.
LATCHING CURRENT
vs
CASE TEMPERATURE
100
V
supply
I
GTM
+
+
-
-
+
-
-
+
TC05AE
V
AA
= ± 12 V
I
L
- Latching Current - mA
10
1
-60
-40
-20
0
20
40
60
80
100
120
T
C
- Case Temperature - °C
Figure 5.
PRODUCT
INFORMATION
3
TIC206 SERIES
SILICON TRIACS
DECEMBER 1971 - REVISED MARCH 1997
MECHANICAL DATA
TO-220
3-pin plastic flange-mount package
This single-in-line package consists of a circuit mounted on a lead frame and encapsulated within a plastic
compound. The compound will withstand soldering temperature with no deformation, and circuit performance
characteristics will remain stable when operated in high humidity conditions. Leads require no additional
cleaning or processing when used in soldered assembly.
TO220
4,70
4,20
ø
3,96
3,71
10,4
10,0
2,95
2,54
6,6
6,0
15,90
14,55
1,32
1,23
see Note B
see Note C
6,1
3,5
0,97
0,61
1
2
3
1,70
1,07
14,1
12,7
2,74
2,34
5,28
4,88
2,90
2,40
0,64
0,41
VERSION 1
VERSION 2
ALL LINEAR DIMENSIONS IN MILLIMETERS
NOTES: A. The centre pin is in electrical contact with the mounting tab.
B. Mounting tab corner profile according to package version.
C. Typical fixing hole centre stand off height according to package version.
Version 1, 18.0 mm. Version 2, 17.6 mm.
MDXXBE
PRODUCT
INFORMATION
4
TIC206 SERIES
SILICON TRIACS
DECEMBER 1971 - REVISED MARCH 1997
