T-1 3/4 (
φ
5mm) PACKAGE
SOLID STATE LAMP
Description
The MVL-5A4SG, a green source color device, is made with
InGaN on SiC substrate LED die.
The package is T-1 3/4 (φ
5mm)
water clear plastic type.
7.62
(.300)
5.90
(.230)
MVL-5A4SG
Package Dimensions
φ5.00
(.200)
Unit: mm ( inches
5.47
(.215)
Applications
l
l
l
l
l
Full color displays & moving message signs
Solid state incandescent replacement bulbs
High ambient panel indicators
Color printers & scanners
Medical & Analytical instruments
0.50 TYP.
(.020)
1.00
(.040)
FLAT DENOTES CATHODE
25.40 MIN. (1.000)
1.00MIN.
(.040)
Features
l
l
l
l
2.54
(.100)
A
C
High performance - 2.0mW (505nm)
Superior SiC substrate technology
Excellent chip to chip consistency
High reliability
Notes :
1. Tolerance is ± 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 0.8 mm (.031") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
Parameter
Peak Forward Current(1/10 Duty Cycle@1KHz )
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Electrostatic Discharge Threshold
Symbol
I
pf
I
af
V
R
T
opr
T
stg
E
ot
100
30
5
@ T
A
=25
o
C
Maximum Rating
Unit
mA
mA
V
-20
o
C
to + 80
o
C
-30
o
C
to + 100
o
C
1000
V
Unity Opto Technology Co., Ltd.
01/09/2002
MVL-5A4SG
Optical-Electrical Characteristics
Parameter
Luminous Intensity
Forward Voltage
Reverse Current
Dominant Wavelength
Viewing Angle
Test Conditions
I
F
=20mA
I
F
=20mA
V
R
=5V
I
F
=20mA
I
F
=20mA
Symbol
I
V
V
F
I
R
λ
d
2θ
1/2
Min .
2500
-
-
-
-
Typ .
5000
3.5
-
505
8
Max .
-
4.0
10
-
-
@ T
A
=25
o
C
Unit .
mcd
V
µA
nm
deg.
Typical Optical-Electrical Characteristic Curves
Relative Luminous Intensity
1
30
Forward Current I
F
(mA)
25
20
15
10
5
0
0
1
2
3
4
0.5
0
380
450
520
590
660
Wavelength (nm)
FIG.1 RELATIVE LUMINOUS INTENSITY
VS. WAVELENGTH
Forward Current I
F
(mA)
40
30
20
10
0
Forward Voltage (V)
FIG.2 FORWARD CURRENT
VS. FORWARD VOLTAGE
Relative Luminous Intensity
Normalized at I
F
=20mA
1.50
1.25
1.00
0.75
0.50
0.25
0.00
0
5
10 15 20 25 30
Ambient Temperature (
o
C
)
FIG.3 FORWARD CURRENT
VS. AMBIENT TEMPERATURE
Relative Luminous Intensity
Relative Luminous Intensity
10
0
25
50
75
100
Forward Current I
F
(mA)
FIG.4 RELATIVE LUMINOUS INTENSITY
VS. FORWARD CURRENT
0
o
10
o
20
o
30°
40°
1.0
0.9
0.8
0.5 0.3 0.1 0.2 0.4 0.6
50°
60°
70°
80°
90°
1
0.1
Ambient Temperature (
o
C
)
FIG.5 RELATIVE LUMINOUS INTENSITY
VS. AMBIENT TEMPERATURE
0
20
30
50
70
90
FIG.6 RADIATION DIAGRAM
Unity Opto Technology Co., Ltd.
Unity Opto Technology Co., Ltd.
01/09/2002
