MOC8111X,MOC8112X,MOC8113X
MOC8111, MOC8112, MOC8113
NON-BASE LEAD
OPTICALLY COUPLED ISOLATOR
PHOTOTRANSISTOR OUTPUT
APPROVALS
l
UL recognised, File No. E91231
'X' SPECIFICATION APPROVALS
l
VDE 0884 in 3 available lead forms : -
- STD
-
G form
-
SMD approved to CECC 00802
l
BSI approved - Certificate No. 8001
DESCRIPTION
The MOC8111, MOC8112, MOC8113 series of
optically coupled isolators consist of infrared
light emitting diode and NPN silicon photo
transistor in a standard 6 pin dual in line plastic
package with the base pin unconnected.
FEATURES
l
Options :-
10mm lead spread - add G after part no.
Surface mount - add SM after part no.
Tape&reel - add SMT&R after part no.
l
High Isolation Voltage (5.3kV
RMS
,7.5kV
PK
)
l
Base pin unconnected for improved noise
immunity in high EMI environment
APPLICATIONS
l
DC motor controllers
l
Industrial systems controllers
l
Signal transmission between systems of
different potentials and impedances
2.54
7.0
6.0
1.2
7.62
6.62
1
2
3
Dimensions in mm
6
5
4
7.62
4.0
3.0
0.5
13°
Max
0.26
3.0
0.5
3.35
ABSOLUTE MAXIMUM RATINGS
(25°C unless otherwise specified)
Storage Temperature
-55°C to + 150°C
Operating Temperature
-55°C to + 100°C
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs) 260°C
INPUT DIODE
Forward Current
Reverse Voltage
Power Dissipation
60mA
6V
105mW
OUTPUT TRANSISTOR
Collector-emitter Voltage BV
CEO
Emitter-collector Voltage BV
ECO
Power Dissipation
POWER DISSIPATION
0.6
0.1
10.46
9.86
OPTION SM
SURFACE MOUNT
OPTION G
30V
6V
160mW
7.62
1.25
0.75
0.26
10.16
Total Power Dissipation
200mW
(derate linearly 2.67mW/°C above 25°C)
ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
31/3/03
DB92197m-AAS/A2
ELECTRICAL CHARACTERISTICS ( T
A
= 25°C Unless otherwise noted )
PARAMETER
Input
Forward Voltage (V
F
)
Reverse Current (I
R
)
Output
Collector-emitter Breakdown (BV
CEO
)
( Note 2 )
Emitter-collector Breakdown (BV
ECO
)
Collector-emitter Dark Current (I
CEO
)
Output Collector Current ( I
C
)
MOC8111
MOC8112
MOC8113
Collector-emitter Saturation VoltageV
CE (SAT)
Input to Output Isolation Voltage V
ISO
5300
7500
Input-output Isolation Resistance R
ISO
5x10
10
Response Time (Rise), tr
Response Time (Fall), tf
2
2
30
6
50
MIN TYP MAX UNITS
1.15
1.5
10
V
µ
A
TEST CONDITION
I
F
= 10mA
V
R
= 6V
I
C
= 1mA
I
E
= 100
µ
A
V
CE
= 10V
10mA I
F
, 10V V
CE
10mA I
F
, 10V V
CE
10mA I
F
, 10V V
CE
10mA I
F
, 0.5mA I
C
See note 1
See note 1
V
IO
= 500V (note 1)
V
CC
= 5V , I
F
= 10mA
R
L
= 75
Ω
(FIG 1)
V
V
nA
Coupled
2
5
10
0.15
0.4
mA
mA
mA
V
V
RMS
V
PK
Ω
µ
s
µ
s
Note 1
Note 2
Measured with input leads shorted together and output leads shorted together.
Special Selections are available on request. Please consult the factory.
FIGURE1
31/3/03
DB92197m-AAS/A2
Collector Power Dissipation vs. Ambient Temperature
200
Collector power dissipation P
C
(mW)
Collector Current vs. Collector-emitter Voltage
50
T
A
= 25°C
50
30
20
15
20
10
0
10
I
F
= 5mA
150
Collector current I
C
(mA)
40
30
100
50
0
-30
0
25
50
75
100
125
Ambient temperature T
A
( °C )
Forward Current vs. Ambient Temperature
80
Current transfer ratio CTR (%)
70
Forward current I
F
(mA)
60
50
40
30
20
10
0
-30
0
25
50
75
100
125
Ambient temperature T
A
( °C )
Relative Current Transfer Ratio
vs. Ambient Temperature
1.5
0
2
4
6
8
10
Collector-emitter voltage V
CE
( V )
Current Transfer Ratio vs. Forward Current
320
280
240
200
160
120
80
40
0
1
2
5
10
20
50
Forward current I
F
(mA)
Collector-emitter Saturation
Voltage vs. Ambient Temperature
0.14
0.12
0.10
0.08
0.06
0.04
0.02
0
-30
0
25
50
75
100
Ambient temperature T
A
( °C )
DB92197m-AAS/A2
V
CE
= 10V
T
A
= 25°C
MOC8113
MOC8112
MOC8111
Collector-emitter saturation voltage V
CE(SAT)
(V)
Relative current transfer ratio
I
F
= 10mA
V
CE
= 10V
I
F
= 10mA
I
C
= 0.5mA
1.0
0.5
0
-30
0
25
50
75
Ambient temperature T
A
( °C )
100
31/3/03
