W005 THRU W10
1.5A SINGLE-PHASE SILICON BRIDGE RECTIFIERS
Reverse Voltage – 50 to 1000 Volts
Forward Current – 1.5 Amperes
Features
•
Surge overload rating – 50 amperes peak
•
Ideal for printed circuit boards
•
Reliable low cost construction utilizing molded
plastic technique results in inexpensive product
•
Mounting Position: Any
Absolute Maximum Ratings and Characteristics
Ratings at 25 Cambient temperature unless otherwise specified. Single-phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
o
Symbols W005
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
at T
A
= 25
O
C
Peak forward surge current ,
8.3mS single half sine-wave superimposed
on rated load
Rating for fusing (t<8.35ms)
Maximum forward voltage drop per element at 1A peak
Maximum reverse current at rated T
A
= 25 C
DC blocking voltage per element T
A
= 100
O
C
Operating temperature range
Storage temperature range
O
W01
100
70
100
W02
200
140
200
W04
400
280
400
1.5
W06
600
420
600
W08
800
560
800
W10 Units
1000
800
1000
V
V
V
A
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
I
FSM
I
2
t
V
F
I
R
T
J
T
A
50
5
1
10
1.0
-50 to +125
-50 to +150
A
A
2
t
V
µA
mA
O
O
C
C
SEMTECH ELECTRONICS LTD.
®
(Subsidiary
of Semtech International Holdings Limited, acompany
listed on the Hong Kong Stock Exchange, Stock Code: 724)
Dated : 03/12/2002
W005 THRU W10
RATING AND CHARACTERISTICS CURVES
FIG. 1-MAXIMUM FORWARD SURGE CURRENT
60
1.6
FIG. 2-DERATING CURVE
OUTPUT RECTIFIED CURRENT
PEAK FORWARD SURGE CURRENT
AMPERES
BRIDGE OUTPUT
FULL WAVE RECTIFIED CURRENT
AVERAGE AMPERES
100
50
40
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
20
40
60
80
100
120
140
30
T
J
=25oC
20
10
1
0
1
10
NUMBER OF CYCLES AT 60Hz
AMBIENT TEMPERATURE,
o
C
FIG. 3-TYPICAL FORWARD
CHARACTERISTICS
10
T
J
=25oC
10
FIG. 4-TYPICAL REVERSE
CHARACTERISTICS
INSTANTANEOUS REVERSE
CURRENT, AMPERES
TYPICAL
DISTRIBUTION
1.0
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
1.0
0.1
0.1
0.01
0.4
0
0.6
0.8
1.0
1.2
1.4
0
20
40
60
80
100
120
140
INSTANTANEOUS FORWARD VOLTAGE, VOLTS
PERCENT OF RATED PEAK
REVERSE VOLTAGE
SEMTECH ELECTRONICS LTD.
®
(Subsidiary
of Semtech International Holdings Limited, acompany
listed on the Hong Kong Stock Exchange, Stock Code: 724)
Dated : 03/12/2002
