PC 2001-L
OUTLINE DIMENSION & BLOCK DIAGRAM
90.9
9.9
4.0
2.54
162.0
149.0
142.8
H1
H2
16
15
40.0 0.5
32.0
17.78
(P2.54 x 7)
2
1
2.0
HOLE 16- 1.0
PAD 16- 1.8
20.0
K
10.0
14.54
23.0
35.4
A
4.0
12.38
HOLE 4- 3.5
172.0
180.0 0.5
4.0
1.6
7.2
DB7
DB0
E
R/W
RS
V
ss
V
dd
Vo
A
K
COM 16
LCD
CONTROLLER
LSI
SEG 40
LCD PANEL
1.152
0.06
SEG 60
6.0
1.765
CONTROL SIGNALS 4
SEGMENT DRIVER
BACKLIGHT
The tolerance unless classified
0.3mm
MECHANICAL SPECIFICATION
Overall Size
View Area
Dot Size
Dot Pitch
180.0 x 40.0
149.0 x 23.0
1.152 x 1.765
1.212 x 1.825
Module
W /O B/L
EL B/L
LED B/L
H2 / H1
5.2 / 9.8
5.2 / 9.8
10.7 / 15.3
PIN ASSIGNMENT
Pin no.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Symbol
Vss
Vdd
Vo
RS
R/W
E
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
A
K
Function
Power supply(GND)
Power supply(+)
Contrast Adjust
Register select signal
Data read / write
Enable signal
Data bus line
Data bus line
Data bus line
Data bus line
Data bus line
Data bus line
Data bus line
Data bus line
Power supply for LED B/L (+)
Power supply for LED B/L ( )
ABSOLUTE MAXIMUM RATING
Symbol Condition
Vdd-Vss
25
o
C
Supply for logic voltage
25
o
C
LCD driving supply voltage
Vdd-Vee
Input voltage
25
o
C
Vin
Item
Min.
-0.3
-0.3
-0.3
Max. Units
V
7
13
V
Vdd+0.3 V
ELECTRICAL CHARACTERISTICS
Item
Symbol Condition Min.
Typical
Max. Units
Power supply voltage
Vdd-Vss
25
o
C
2.7
5.5
V
Top
N W N W N W V
o
C
7.9
V
-20
7.1
7.5
LCD operation voltage
Vop
V
3.9 6.1 4.2 6.4 4.5 6.7
V
o
C
50
4.2
3.6
3.9
V
o
C
6.3
V
6
70
5.7
2
3
Vdd=5V
mA
VB/L=4.2V
mA
VB/L=4.2V
mA
360
4.3
4.6
4.9
25
o
C
0
o
C
LCM current consumption (No B/L)
Idd
LED/edge
LED/array
Backlight current consumption
LCD option: STN, TN, FSTN
Backlight Option: LED,EL Backlight feature, other Specs not available on catalog is under request.
14.54
0.06
