1310 nm LASER DIODE MODULES
UNCOOLED MQW-FP LD WITH PIGTAIL
FEATURES
²
²
²
²
1310 nm typical emission wavelength
High reliability, long operation life
High temperature operation without active cooling
Build-in InGaAs monitor
FL-3300
********************************************************************************************************************************************************
FL-3300 SERIES
*******************************************************************************************************************************************************
APPLICATION
Trunk Line, FitL
DESCRIPTION
FL-3300 series are designed for coupling a single mode optical fiber with 1310 nm MQW-FP uncooled
laser diode. FL-3300 series are the best kits as light sources for telecom and datacom applications.
ELECTRICAL AND OPTICAL CHARACTERISTICS (T
C
=25
°C)
Symbol
I
th
V
OP
P
f
Parameter
Threshold Current
Operating Voltage
Optical Output Power
Part No:FL-330X
FL-331X
FL-332X
FL-333X
Center Wavelength
Spectral Width
Rise And Fall Times
Tracking Error
PD Monitor Current
PD Dark Current
CW
CW, I
F
= I
th
+20mA
CW, I
F
= I
th
+20mA
0.2
0.5
1.0
2.0
1290
-
-
-
1310
1
-
-
-
1330
3
0.3
-
100
0.1
-
±1.0
mW
Test Conditions
Min.
Typ.
12
1.2
Max.
15
1.5
Unit
mA
V
λc
Δλ
t
r
, t
f
ΔP
f
/ P
f
I
m
I
D
CW, I
th
+20mA
CW, I
th
+20mA
,
RMS (σ)
I
F
=I
th
, I
th
+20mA , 10~ 90%
APC, -40~+85
ºC
CW, I
th
+20mA,V
RD
=1V
V
RD
=5V
nm
nm
ns
dB
μA
μA
C
t
PD Capacitance
V
RD
=5V, f=1MHz
10
15
pF
ABSOLUTE MAXIMUM RATINGS (T
C
=25
ºC)
Symbol
P
o
V
RL
V
RD
I
FD
T
opr
T
stg
Parameter
Optical Output Power
(330X/331X/332X/333X)
LD Reverse Voltage
PD Reverse Voltage
PD Forward Current
Operating Temperature
Storage Temperature
Ratings
0.5/1.0/1.5/3
2
10
1.0
-40~+85
-40~+85
Unit
mW
V
V
mA
ºC
ºC
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
2/18/2002 V1.0
Optoway
MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT
FL-3300
********************************************************************************************************************************************************
FL-330X
FL-331X
FL-332X
FL-333X
Note:
Specifications subject to change without notice.
ORDER INFORMATION
Part No.: F
Code
0
1
2
3
L
−
3 3
□
□
□
−
□
Code
V
H
X
□ □
□
Code
Blank
S
Isolator
No
Single-Stage
Pout (mw)
0.2
0.5
1
2
Flange
Vertical
Horizontal
No Flange
Code Pin Assignment
0
Type A
5
Type B
8
Type C
Code
Blank
S
Speed
1.25 Gbps
2.5 Gbps
Code
S
F
T
X
SA
FA
TA
Connector
SC/PC
FC/PC
ST/PC
No connector
SC/APC
FC/APC
ST/APC
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
2/18/2002 V1.0
