LED - Lamp
22.04.2008
Radiation
Infrared
Type
DDH
Technology
AlGaAs/AlGaAs
ELD-880-015
rev. 01
Case
TO-46 + Glass Lens
Description
± 0,2
± 0,2
ANODE
2 - Ø0,45
Ø 5,4
Au-Plating
Ni-Plating Glass Lens
High-power, high-speed LED with narrow beam
angle and high reliability, housing in TO-46.
2,54
1,
0
CATHODE
0,4
4,5
25,5
± 1,0
4,6
± 0,2
Maximum Ratings
T
amb
= 25° unless otherwise specified
C,
Parameter
Forward current (DC)
Peak forward current
Power dissipation
Operating temperature range
Storage temperature range
Junction temperature
Lead soldering temperature
< 5 s, 3.0 mm from case
(t
P
= 100
µs,
D = 0,1)
Test
сonditions
Symbol
I
F
I
FM
P
D
T
amb
T
stg
T
J
T
sol
Value
100
400
200
-30 to +100
-40 to +125
125
260
Unit
mA
mA
mW
°
C
°
C
°
C
°
C
Optical and Electrical Characteristics
T
amb
= 25° unless otherwise specified
C,
Test
Parameter
conditions
I
F
= 20 mA
Forward voltage
Forward voltage
1
Reverse voltage
Radiant power
Radiant power
1
Radiant intensity
Radiant intensity
1
Peak wavelength
Spectral bandwidth at 50%
Viewing angle
Switching time
1
for information only
We reserve the right to make changes to improve technical design and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each application by the customers themselves.
EPIGAP
Optoelektronik GmbH, D-12555 Berlin, Köpenicker Str.325 b, Haus 201
Tel.: +49-30-6576 2543, Fax : +49-30-6576 2545
1 of 3
Note: All measurements carried out on
EPIGAP
equipment
0
1,
Applications
± 0,5
45°
6,2
Optical communications, safety equipment,
automation
Symbol
V
F
V
F
V
R
Φ
e
Φ
e
Ι
e
Ι
e
λ
p
∆λ
0.5
ϕ
t
r,
t
f
Min
Typ
1.4
1.5
Max
1.8
Unit
V
V
V
I
F
= 50 mA
I
R
= 10 µA
I
F
= 20 mA
I
F
= 50 mA
I
F
= 20 mA
I
F
= 50 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
5
1.4
1.8
4.5
25
40
100
865
880
45
8
25
890
mW
mW
mW/sr
mW/sr
nm
nm
deg.
ns
LED - Lamp
22.04.2008
R
adiant Pow vs. Forw Current (typical)
er
ard
Norm
alized to
Φ
e
@I
F
= 20 m
A
120
5
ELD-880-015
rev. 01
ForwardCurrent vs. Forw Voltage (typical)
ard
6
Rel. Radiant Power
Φ
e
(rel.)
4
Forward Current
I
F
(mA)
100
80
3
60
2
40
1
20
0
0
20
40
60
80
100
120
1,0
1,2
1,4
1,6
1,8
Forward Current
I
F
(mA)
Forward Voltage
U
F
(V)
Spectral Power Distribution (typical)
A
at I
F
= 20 m
1,0
100
A bient Tem
m
perature vs. M al Forward Current
axim
0,8
Max. Forward Current (mA)
750
800
850
900
950
1000
1050
Rel. Intensity (arb. units)
80
0,6
60
0,4
40
0,2
20
0,0
700
0
-40
-20
0
20
40
60
80
100
120
Wavelength (nm)
Ambient Temperature (°
C)
We reserve the right to make changes to improve technical design and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each application by the customers themselves.
EPIGAP
Optoelektronik GmbH, D-12555 Berlin, Köpenicker Str.325 b, Haus 201
Tel.: +49-30-6576 2543, Fax : +49-30-6576 2545
2 of 3
LED - Lamp
22.04.2008
ELD-880-015
rev. 01
Remarks concerning optical radiation safety*
Up to maximum forward current, at continuous operation, this LED may be classified as LED product
Class 1
, according to standard IEC 60825-1:A2.
Class 1
products are safe to eyes and skin under
reasonably predictable conditions. This implicates a direct observation of the light beam by means of
optical instruments.
*Note: Safety classification of an optical component mainly depends on the intended application and
the way the component is being used. Furthermore, all statements made to classification are based
on calculations and are only valid for this LED "as it is", and at continuous operation. Using pulsed
current or altering the light beam with additional optics may lead to different safety classifications.
Therefore these remarks should be taken as recommendation and guideline only.
LED Class 1
accord. DIN EN/IEC 60825-1:2001-11
We reserve the right to make changes to improve technical design and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each application by the customers themselves.
EPIGAP
Optoelektronik GmbH, D-12555 Berlin, Köpenicker Str.325 b, Haus 201
Tel.: +49-30-6576 2543, Fax : +49-30-6576 2545
3 of 3
