SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 4074, REV. D
SHD626051
SHD626051P
SHD626051N
SHD626051D
HERMETIC SILICON CARBIDE RECTIFIER
DESCRIPTION:
A 600-VOLT, 20 AMP POWER SILICON CARBIDE RECTIFIER IN A HERMETIC TO-257
PACKAGE AVAILABLE SCREENED TO ANY REQUIRED LEVEL
FEATURES:
•
NO RECOVERY TIME OR REVERSE RECOVERY LOSSES
•
NO TEMPERATURE INFLUENCE ON SWITCHING BEHAVIOR
•
High Temperature Option
- Maximum operation & storage temperature can be increased to 250
o
C;
use part number prefix as SHDT
•
High Frequency Option
- Non-magnetic Glidcop leads are available for improved performance at
high frequency; use part number prefix SHDG
•
Ceramic Seal Option
– For ceramic seals use part number prefix SHDC
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
MAXIMUM DC OUTPUT CURRENT (With T
C
= 65
O
C, for part numbers with P and
N suffixes)
MAXIMUM DC OUTPUT CURRENT (With T
C
= 65
O
C, for part numbers with Single
and D suffixes)
MAXIMUM REPETITIVE FORWARD SURGE CURRENT PER LEG
(t = 8.3ms, Sine) per leg, T
C
= 25
O
C
MAXIMUM NON-REPETITIVE FORWARD SURGE CURRENT PER LEG
(t = 10µs, Pulse) per leg, T
C
= 25
O
C
MAXIMUM JUNCTION CAPACITANCE (V
r
=5V) per leg
MAXIMUM POWER DISSIPATION, T
C
= 25
O
C,
MAXIMUM THERMAL RESISTANCE, Junction to Case (PER DUAL PACKAGE
For Common Cathode/Anode Configurations)
MAXIMUM OPERATING AND STORAGE TEMPERATURE RANGE
ALL RATINGS ARE @ T
C
= 25
°C
UNLESS OTHERWISE SPECIFIED.
SYMBOL
PIV
I
O
I
O
I
FRM
I
FSM
MAX.
600
20
10
UNITS
Volts
Amps
Amps
Amps
Amps
50
250
C
T
P
d
R
θ
JC
Top, Tstg
350
40
2.1
-55 to
+175
pF
W
°C/W
°C
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP
Pulsed (I
f
= 10 A PER LEG) V
f
MAXIMUM FORWARD VOLTAGE DROP
Pulsed (I
f
= 6 A PER LEG) V
f
T
J
= 25°C
T
J
= 150
°C
T
J
= 25°C
T
J
= 150
°C
TYP
1.65
1.85
1.35
1.50
0.04
0.08
40
MAX.
1.75
1.95
1.45
1.60
0.15
0.50
N/A
UNITS
Volts
Volts
MAXIMUM REVERSE CURRENT (I
r
@ 600V PIV PER LEG) T
J
= 25
°C
T
J
= 150
°C
TOTAL CAPACITIVE CHARGE (V
R
=600V I
F
=10A di/dt=500A/µs T
J
=25°C) Q
C
per
leg
mA
nC
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 4074, REV. D
SHD626051
SHD626051P
SHD626051N
SHD626051D
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 4074, REV. D
SHD626051
SHD626051P
SHD626051N
SHD626051D
MECHANICAL DIMENSIONS
TO-257
.150 (3.81
.140 3.56)
.200 (5.08
Dia.
.420 (10.67
.410 10.41)
.190 4.82)
.045 (1.14
.035 0.89)
.537 (13.64
.527 13.39)
1.132 (28.75
1.032 26.21)
.665 (16.89
.645 16.38)
.430 (10.92
.410 10.41)
1
2
3
.035 (0.89
.025 0.63)
3 Places
.100(2.54) BSC
2 Places
.120(3.05) BSC
PINOUT TABLE
TYPE
SINGLE RECTIFIER
DUAL RECTIFIER/COMMON CATHODE (P)
DUAL RECTIFIER/COMMON ANODE (N)
DUAL RECTIFIER/DOUBLER (D)
PIN 1
CATHODE
ANODE 1
CATHODE 1
ANODE
PIN 2
ANODE
COMMON
CATHODE
COMMON
ANODE
ANODE/
CATHODE
PIN 3
ANODE
ANODE 2
CATHODE 2
CATHODE
SCHEMATIC
1
2
SINGLE
3
1
2
3
COMMON CATHODE
1
2
3
COMMON ANODE
3
2
DOUBLER
1
Application Note: Customers should be aware that at the current stage of technical development of SiC, the reverse avalanche
capabilities of the device are limited.
Customer designs will need to accommodate these limitations and avoid exposure of the device to this and other potentially
damaging conditions in their applications.
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version
of the datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment,
medical equipment, and safety equipment), safety should be ensured by using semiconductor devices that feature assured safety or by
means of users’ fail-safe precautions or other arrangement.
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during
operation of the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual
property claims or any other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from
use at a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of
Sensitron Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will
hinder maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third
party. When exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and
regulations.
•
221 West Industry Court
Deer Park, NY 11729-4681
(631) 586-7600 FAX (631) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-Mail Address - sales@sensitron.com
•
