PB42WG-4809E21: Description1.5 kvdc isolated 10 W regulated single output; File Size128KB，2 Pages; ManufacturerPEAK electronics; Websitehttp://www.peak-electronics.de/

Download Datasheet View All

PB42WG-4809E21 Overview

1.5 kvdc isolated 10 W regulated single output

Preview

Download Datasheet

View All

Telefon: +49 (0) 6135 931069

Telefax: +49 (0) 6135 931070

www.peak-electronics.de

info@peak-electronics.de

B7 SERIES

PB42WG-XXXXE2:1 1.5 KVDC ISOLATED 10 W REGULATED SINGLE OUTPUT

Available Inputs: 12, 24 and 48 VDC Wide Input 2:1

Available Outputs: 3.3, 5, 9, 12 and 15 VDC

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

9 -18 VDC (12 VDC), 18 - 36 VDC (24 VDC), 36 -

72 VDC (48 VDC)

Pi Filter

1500 Vdc

Ohm

350 pF typ.

+/- 1 % typ. +/-2% max.

50 mV p-p typ. , 100/120 mV p-p (12/15 VDC

Output)

Continuous , restart automatic

+/- 0,5 % max.

+/- 0,02 % / °C

79 % to 84 %

250 KHz, typ.

-25°C to +71°C

- 55 °C to + 105 °C

Examples of Partnumbers/Modelcode

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL

LOAD

(% TYP.)

PB42WG-123R3E2:1

PB42WG-1205E2:1

PB42WG-1209E2:1

PB42WG-12122:1

PB42WG-1215E2:1

PB42WG-243R3E2:1

PB42WG-2405E2:1

PB42WG-2409E2:1

PB42WG-2412E2:1

PB42WG-2415E2:1

PB42WG-483R3E2:1

PB42WG-4805E2:1

PB42WG-4809E2:1

PB42WG-4812E2:1

PB42WG-4815E2:1

9 –18

18 – 36

36 – 72

36 - 72

870

1042

1006

1000

982

441

515

503

506

497

223

254

248

250

246

3.3

2500

2000

1100

830

660

2500

2000

1100

830

660

2500

2000

1100

830

660

Remark:

1. Input Current is measured at Norminal Input Voltage, 9-18 is @ 12V, 18-36 is @ 24V, 36-72 is @ 48V
