8
VICOR CONFIDENTIAL
7
6
5
4
3
2
REVISIONS
1
F
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
REV
1
2
3
4
DESCRIPTION
RELEASED PER E060496
REVISED PER E060064
REVISED PER E080938
REVISED PER E101309
DATE
APPROVED
MB
MB
REJH
AR
F
LEK
GCK
SA
2/15/06
12/6/06
5/6/08
.78 MAX
2
E
5
6
4
SEE NOTE 7
SEE NOTE 8
7
KUK
10/22/10
E
D
.70
TYP REF
.35
TYP REF
1
D
C
.20
TYP REF
C
.40
TYP REF
3
.35
MAX
SEATING
PLANE
.50
LEAD LENGTH
.30
(TIN TO SEATING
PLANE MINIMUM)
4PLCS
B
REF P/N 31943
REF P/N 33884
NOTES:
1. ASSEMBLY TO BE FREE OF NICKS.
2. WINDINGS TO BE EVENLY SPACED.
3. RoHS COMPLIANT. LEAD FREE PER CST-0001LATEST REVISION.
4. GENERAL WORKMANSHIP STANDARDS FOR MAGNETIC COMPONENTS PER WS-0002.
5. OVERWINDS PERMISSIBLE
6. LEADS CONFORMABLE TO LEAD DIMENSION
7. BOND SPACER (ITEM 4) TO CORE (ITEM 1) USING ADHESIVE (ITEMS 5 & 6) OR EQUIVALENT-ONE
END ONLY-AS SHOWN.
8. WIND FINISHED ASSY WITH TWO WRAPS OF TAPE (ITEM 7).
9. DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
8
7
6
5
DRAWN
KNIGHT
MATERIAL
SEE NOTES
B
SWD
DATE
2/15/06
VICOR
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
IND TOROID .78 DIA 2W
ASSY DWG
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
SEE NOTES
B
DO NOT SCALE DRAWING
67131
2
31947
SHEET 1 OF 1
4
1
A
SCALE 4 : 1
4
3
