SB140H~SB1100H
Power Schottky Rectifier - 1Amp 40~100Volt
□
Features
-Low forward voltage drop
-High current capability
-High reliability
-High surge current capability
-Epitaxial construction
-Halogen-Free
DO-41
□
Mechanical data
-Case：Molded plastic
-Epoxy：UL 94V-0 rate flame retardant
-Lead：Axial leads, solderable per MIL-STD-202,method 208 guaranteed
-Polarity：Color band denotes cathode end
-Mounting position：Any
-Weight：0.34 grams
.107(2.7)
.080(2.0)
.034(0.9)
.028(0.7)
□
Maximum ratings and Electrical characteristics
TYPE
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3ms single half sine-wave
superimposed on rated load(JEDEC method)
Maximum Instantaneous Forward Voltage at 1.0A
Maximum DC Reverse Current at Rated
DC Blocking Voltage
Typical Junction Capacitance
Typical Thermal Resistance R
θ
JA
Operating Temperature Range T
J
Storage Temperature Range T
STG
Note: Pulse Test : 380μs pulse width, 2% duty cycle
June 2009 / Rev.6.4
SB140H
40
28
40
SB160H
60
42
60
1.0
30
SB1100H
100
70
100
1.0(25.4)
.205(5.2)
.166(4.2)
1.0(25.4)
UNIT
V
V
V
A
A
0.55
0.5
20
0.65
0.3
15
110
50
-50 to +150
-50 to +150
0.82
0.01
10
V
mA
pF
ºC/W
Ta = 25ºC
Ta = 100ºC
-50 to +175
ºC
ºC
http:// www.sirectsemi.com
1
SB140H~SB1100H
1.4
AVERAGE FORWARD CURRENT
AMPERES
1.2
1.0
0.8
100
INSTANTANEOUS FORWARD CURRENT , (A)
SB
H
00
11
0.6
0.4
0.2
0
0
25
50
75
10
H
40
B1
S
AMBIENT TEMPERATURE ,
℃
Figure 1. Forward Current Derating Curve
B1
-S
0H
14
SB
H
60
100
125
H
60
H
B1
S
00
11
SB
1
150
175
200
0.1
T
J
=25ºC
Pulse Width 300μs
1% Duty Cycle
0.01
0.1
0.3
0.5
0.7
0.9
1.1
1.3
1.5
30
PEAK FORWARD SURGE CURRENT
AMPERES
24
FORWARD VOLTAGE , VOLTS
18
Figure 4. Typical Forward Characteristics
12
6
Single Half-Sine-Wave
(JEDEC METHOD)
100
0
1
2
5
10
20
50
100
NUMBER OF CYCLES AT 60Hz
REVERSE LEAKAGE CURRENT , (mA)
10
Figure 2. Maximum Non-repetitive Surge Current
350
300
1
T
j
= 75℃
CAPACITANCE , (pF)
250
200
150
100
50
0.1
T
j
= 25℃
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE , (%)
0
0.01
0.1
1
10
100
Figure 5. Typical Reverse Characteristics
REVERSE VOLTAGE , VOLTS
Figure 3. Typical Junction Capacitance
Sirectifier Global Corp., Delaware, U.S.A.
U.S.A.:
sgc@sirectsemi.com
France:
ss@sirectsemi.com
Taiwan:
se@sirectsemi.com
Hong Kong:
hk@sirectsemi.com
China:
st@sirectsemi.com
…Thailand:
th@sirectsemi.com
Philippines:
aiac@sirectsemi.com
Belize:
belize@sirectsemi.com
http:// www.sirectsemi.com
2
