Terminal Junction Modules

M81714/5, /10, /16 Series I

Terminal Junction Module Mounting Tracks

Operating Range

Temperature:

-65º to 200ºC

Corrosion:

No Exposure of Base Metal

After 48 Hours of Salt Spray

Magnetic Permeability:

2.0 MU Max.

Vibration and Shock:

Per MIL-T-81714 Paragraph

3.5.5 and 3.5.8

Materials

Rail:

Aluminum Alloy, Black Anodized

Finish per MIL-A-8625

Locking Clamp Screw:

Corrosion Resistent, Passivated,

Self Locking

Product Description

Amphenol Pcd offers feedback and feedthru mounting tracks,

as well as a light weight feedback type with weight reduction

cutouts per MIL-T-81714/16 for weight critical applications.

One track holds all module sizes. With size 22,20,16 modules

requiring one mounting

space and size 12 requiring three.

Each track unit consists of an aluminum alloy track and

MIL-T-81714/16 anodized black locking clamp. The stainless

steel clamp screw is self locking to meet vibration, shock and

temperature variation requirements.

Feedback Track Dimensions

STANDARD

LIGHTWEIGHT

Feedback Mounting Tracks

Standard

Military P/N

M81714/5-1

M81714/5-2

M81714/5-3

M81714/5-4

M81714/5-5

M81714/5-6

M81714/5-7

M81714/5-8

M81714/5-9

M81714/5-10

M81714/5-11

M81714/5-12

Lightweight

Military P/N

M81714/16-1

M81714/16-2

M81714/16-3

M81714/16-4

M81714/16-5

M81714/16-6

M81714/16-7

M81714/16-8

M81714/16-9

M81714/16-10

M81714/16-11

M81714/16-12

M81714/16-13

Dimensions

Mounting Pos.*

APCD P/N

TJT701010

TJT701002

TJT701003

TJT701004

TJT701005

TJT701006

TJT701007

TJT701008

TJT701009

TJT701011

TJT701012

TJT701013

TJT701014

TJT701015

TJT701016

TJT701017

TJT701018

TJT701019

TJT701020

APCD P/N

TJT703010

TJT703002

TJT703003

TJT703004

TJT703005

TJT703006

TJT703007

TJT703008

TJT703009

TJT703011

TJT703012

TJT703013

TJT703014

TJT703015

TJT703016

TJT703017

TJT703018

TJT703019

TJT703020

5.29

2.17

2.56

2.95

3.34

3.73

4.12

4.51

4.90

5.68

6.07

6.46

6.85

7.24

7.63

8.02

8.41

8.80

9.19

4.79

1.67

2.06

2.45

2.84

3.23

3.62

4.01

4.40

5.18

5.57

5.96

6.35

6.74

7.13

7.52

7.91

8.30

8.69

HOLE FOR #6 FLAT HEAD SCREW

M81714/5-13

1.070

.970

1.120

Divide by 3 for Size 12 Module Mounting

Feedthru Track Dimensions

Feedthru Mounting Tracks

Standard

Military P/N

APCD P/N

TJT702010

TJT702002

M81714/10-2

M81714/10-3

M81714/10-4

M81714/10-5

TJT702003

TJT702004

TJT702005

TJT702006

TJT702007

TJT702008

TJT702009

Dimensions

Mounting Pos.*

A”

5.55

2.43

2.82

3.21

3.60

3.90

4.38

4.77

5.16

B”

5.05

1.91

2.32

2.71

3.10

3.49

3.88

4.27

4.66

1.120

M81714/10-1

1.890

M81714/10-6

M81714/10-7

M81714/10-8

Amphenol Pcd

Divide by 3 for Size 12 Module Mounting

www.amphenolpcd.com

Milaero@amphenolpcd.com

1-978-624-3400

72 Cherry Hill Drive Beverly, MA 01915
