5V VCXO
Specifications
GVXO-41
GVXO-41F: Full size (14 pin DIL)
GVXO-41H: Half size (8 pin DIL)
Parameters
Package:
14 pin DIL (full size)
8 pin DIL (half size)
1.544 ~ 33.0MHz
1.544 ~ 30.0MHz
13.08
(max)
Variant
F
H
Option
Codes
20.80
(max)
13.08
(max)
Frequency range:
13.08
(max)
Voltage control:
+2.5V ±2.5V, 10% linearity
>100k input impedance
Frequency pullability (min):
±80ppm
±150ppm
±200ppm
Frequency stability:
±100ppm
±50ppm
±25ppm
±20ppm
±15ppm
N
S
W
A
B
C
D
E
0.80
0.46Ø
5.70
(max)
4.00
(min)
0.80
0.46Ø
5.70
(max)
4.00
(min)
1
14
7
8
7.62
1
8
4
5
7.62
Ageing:
15.24
PIN
1
7
8
14
CONNECTION
Control voltage
Ground
Output
Supply
PIN
1
4
5
8
7.62
±5.0ppm max per year
Operating temperature range:
-10 to +70°C
-40 to +85°C
Storage temperature range:
-55 to +125°C
Supply voltage (V
DD
):
+5.0V (±5%)
Scale 1:1
Supply current:
20mA max (<20.0MHz)
30mA max (20.0 ~ 33.0MHz)
Driving ability:
30pF HCMOS
5 LSTTL
I
Features
«
«
«
«
«
5.0V supply
Low cost for volume applications
Choice of pullability & stability
Express deliveries for non-standard items
Industrial temperature range option
Logic levels:
‘0’ level = +0.4V max
‘1’ level = 90%V
DD
min
Waveform symmetry @ 50%V
DD
:
40:60 max
Rise / fall time:
6ns max (0.4V ~ 90%V
DD
min)
Standard.
Optional - Please specify required code(s) when ordering
Standard Frequencies
Frequencies in MHz
8.19200
13.50000
14.31818
16.38400
17.73447
Other frequencies available. Please consult our sales office.
19.44000
20.48000
24.57600
27.00000
32.76800
Ordering Information
Product + variant + option codes + frequency
eg:
GVXO-41F/SC 20.480MHz
±150ppm pullability, ±25ppm stability
Option codes must be included to specify a model
completely.
Option code X (eg GVXO-41F/X) denotes a custom spec.
±15ppm and ±20ppm stability may not be available over -40+85°C,
depending on frequency. Check with our sales office.
Tel:
+44 1460 256 100
12 Jul 2001
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
